Spring Boot利用Spring Data JPA实现排序与分页查询实战(附源码，超详细）-阿里云开发者社区

在实际开发场景中，排序与分页查询是必须的，幸运的是Spring Data JPA充分考虑了排序与分页查询的场景，为我们提供Sort类 Page接口 Pageable接口下面通过一个实战来阐明

1：创建持久化实体类

创建名为com.ch.ch6_4.entity的包并在该包中创建名为Article和Author的持久化实体类

代码如下

Article

package com.ch.ch6_2.entity;
import java.io.Serializable;
import javax.persistence.Basic;
import javax.persistence.CascadeType;
import javax.persistence.Column;
import javax.persistence.Entity;
import javax.persistence.FetchType;
import javax.persistence.GeneratedValue;
import javax.persistence.GenerationType;
import javax.persistence.Id;
import javax.persistence.JoinColumn;
import javax.persistence.Lob;
import javax.persistence.ManyToOne;
import javax.persistence.Table;
import javax.validation.constraints.NotEmpty;
import javax.validation.constraints.Size;
import com.fasterxml.jackson.annotation.JsonIgnore;
import com.fasterxml.jackson.annotation.JsonIgnoreProperties;
@Entity
@Table(name = "article_table")
@JsonIgnoreProperties(value = { "hibernateLazyInitializer"})
public class Article  implements Serializable{
  private static final long serialVersionUID = 1L;
  @Id
  @GeneratedValue(strategy = GenerationType.IDENTITY)
  private int id;
  //标题
  @NotEmpty(message = "标题不能为空")
    @Size(min = 2, max = 50)
    @Column(nullable = false, length = 50)
    private String title;
  //文章内容
    @Lob  //大对象，映射 为MySQL的Long文本类型
    @Basic(fetch = FetchType.LAZY)
    @NotEmpty(message = "内容不能为空")
    @Size(min = 2)
    @Column(nullable = false)
    private String content;
    //所属作者，文章与作者是多对一的关系
    @ManyToOne(cascade={CascadeType.MERGE,CascadeType.REFRESH},optional=false)
    //可选属性optional=false,表示author不能为空。删除文章，不影响用户
    @JoinColumn(name="id_author_id")//设置在article表中的关联字段(外键)
    @JsonIgnore
    private Author author;
  public int getId() {
    return id;
  }
  public void setId(int id) {
    this.id = id;
  }
  public String getTitle() {
    return title;
  }
  public void setTitle(String title) {
    this.title = title;
  }
  public String getContent() {
    return content;
  }
  public void setContent(String content) {
    this.content = content;
  }
  public Author getAuthor() {
    return author;
  }
  public void setAuthor(Author author) {
    this.author = author;
  }
}

Author

package com.ch.ch6_2.entity;
import java.io.Serializable;
import java.util.List;
import javax.persistence.CascadeType;
import javax.persistence.Entity;
import javax.persistence.FetchType;
import javax.persistence.GeneratedValue;
import javax.persistence.GenerationType;
import javax.persistence.Id;
import javax.persistence.OneToMany;
import javax.persistence.Table;
import com.fasterxml.jackson.annotation.JsonIgnoreProperties;
@Entity
@Table(name = "author_table")
@JsonIgnoreProperties(value = { "hibernateLazyInitializer"})
public class Author implements Serializable{
  private static final long serialVersionUID = 1L;
  @Id
  @GeneratedValue(strategy = GenerationType.IDENTITY)
  private int id;
  //作者名
  private String aname;
  //文章列表，作者与文章是一对多的关系
    @OneToMany(
        mappedBy = "author",
        cascade=CascadeType.ALL,
        targetEntity = Article.class,
        fetch=FetchType.LAZY
        )
    private List<Article> articleList;
  public int getId() {
    return id;
  }
  public void setId(int id) {
    this.id = id;
  }
  public String getAname() {
    return aname;
  }
  public void setAname(String aname) {
    this.aname = aname;
  }
  public List<Article> getArticleList() {
    return articleList;
  }
  public void setArticleList(List<Article> articleList) {
    this.articleList = articleList;
  }
}

2：创建数据访问层

创建名为com.ch.ch6_4repository的包并在该包中创建名为AuthorRepository的接口

package com.ch.ch6_2.repository;
import org.springframework.data.jpa.repository.JpaRepository;
import org.springframework.data.jpa.repository.Query;
import com.ch.ch6_2.entity.Author;
public interface AuthorRepository extends JpaRepository<Author, Integer>{
  /**
   * 根据文章标题包含的内容，查询作者（关联查询）
   * 相当于JPQL语句：select a from Author a  inner join  a.articleList t where t.title like %?1%
   */
  public Author findByArticleList_titleContaining(String title);
  /**
   * 根据文章标题包含的内容，查询作者（关联查询）
   */
  @Query("select a from Author a  inner join  a.articleList t where t.title like %?1%" )
  public Author findAuthorByArticleListtitleContaining(String title);
}

3：创建业务层

创建名为com.ch.ch6_4.service的包并在该包中创建名为ArticleAndAuthorService的接口和接口实现类ArticleAndAuthorServiceImpl

接口

package com.ch.ch6_2.service;
import java.util.List;
import com.ch.ch6_2.entity.Article;
import com.ch.ch6_2.entity.Author;
public interface AuthorAndArticleService {
  public void saveAll();
  public List<Article> findByAuthor_id(Integer id);
  public List<Article> findByAuthor_aname(String aname);
  public Author findByArticleList_titleContaining(String title);
  public Author findAuthorByArticleListtitleContaining(String title);
}

接口实现类

package com.ch.ch6_2.service;
import java.util.ArrayList;
import java.util.List;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.stereotype.Service;
import com.ch.ch6_2.entity.Article;
import com.ch.ch6_2.entity.Author;
import com.ch.ch6_2.repository.ArticleRepository;
import com.ch.ch6_2.repository.AuthorRepository;
@Service
public class AuthorAndArticleServiceImpl implements AuthorAndArticleService{
  @Autowired
  private AuthorRepository authorRepository;
  @Autowired
  private ArticleRepository articleRepository;
  @Override
  public void saveAll() {
    //保存作者（先保存一的一端）
    Author a1 = new Author();
    a1.setAname("陈恒1");
    Author a2 = new Author();
    a2.setAname("陈恒2");
    ArrayList<Author> allAuthor = new ArrayList<Author>();
    allAuthor.add(a1);
    allAuthor.add(a2);
    authorRepository.saveAll(allAuthor);
    //保存文章
    Article at1 = new Article();
    at1.setTitle("JPA的一对多111");
    at1.setContent("其实一对多映射关系很常见111。");
    //设置关系
    at1.setAuthor(a1);
    Article at2 = new Article();
    at2.setTitle("JPA的一对多222");
    at2.setContent("其实一对多映射关系很常见222。");
    //设置关系
    at2.setAuthor(a1);//文章2与文章1作者相同
    Article at3 = new Article();
    at3.setTitle("JPA的一对多333");
    at3.setContent("其实一对多映射关系很常见333。");
    //设置关系
    at3.setAuthor(a2);
    Article at4 = new Article();
    at4.setTitle("JPA的一对多444");
    at4.setContent("其实一对多映射关系很常见444。");
    //设置关系
    at4.setAuthor(a2);//文章3与文章4作者相同
    ArrayList<Article> allAt = new ArrayList<Article>();
    allAt.add(at1);
    allAt.add(at2);
    allAt.add(at3);
    allAt.add(at4);
    a
  public Author findByArticleList_titleContaining(String title) {
    return authorRepository.findByArticleList_titleContaining(title);
  }
  @Override
  public Author findAuthorByArticleListtitleContaining(String title) {
    return authorRepository.findAuthorByArticleListtitleContaining(title);
  }
}

4：创建控制器类

创建名为com.ch,ch6_4.controller的包并在该包中创建名为TestSortAndPage的控制器类

package com.ch.ch6_4.controller;
import java.util.List;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.stereotype.Controller;
import org.springframework.ui.Model;
import org.springframework.web.bind.annotation.RequestMapping;
import org.springframework.web.bind.annotation.ResponseBody;
import com.ch.ch6_4.entity.Author;
import com.ch.ch6_4.service.ArticleAndAuthorService;
@Controller
public class TestSortAndPage {
  @Autowired
  private ArticleAndAuthorService articleAndAuthorService;
  @RequestMapping("/findByAnameContaining")
  @ResponseBody
  public List<Author> findByAnameContaining(String aname, String sortColum){
    return articleAndAuthorService.findByAnameContaining(aname, sortColum);
  }
  @RequestMapping("/findAllAuthorByPage")
  /**
   * @param page第几页
   */
  public String findAllAuthorByPage(Integer page, Model model){
    return articleAndAuthorService.findAllAuthorByPage(page, model);
  }
}

5：创建View视图页面

创建index.html页面部分代码如下

<!DOCTYPE html>
<html xmlns:th="http://www.thymeleaf.org">
<head>
<meta charset="UTF-8">
<title>显示分页查询结果</title>
<link rel="stylesheet" th:href="@{css/bootstrap.min.css}" />
<link rel="stylesheet" th:href="@{css/bootstrap-theme.min.css}" />
</head>
<body>
  <div class="panel panel-primary">
    <div class="panel-heading">
      <h3 class="panel-title">Spring Data JPA分页查询</h3>
    </div>
              </tr>
              <tr>
              <td colspan="2" align="right">
                <ul class="pagination">
                  <li><a>第<span th:text="${page}"></span>页</a></li>
                  <li><a>共<span th:text="${totalPage}"></span>页</a></li>
                  <li><a>共<span th:text="${totalCount}"></span>条</a></li>
                  <li>
                  <a th:href="@{findAllAuthorByPage(page=${page-1})}" th:if="${page != 1}">上一页</a>
                  </li>
                  <li><a th:href="@{findAllAuthorByPage(page=${page+1})}" th:if="${page != totalPage}">下一页</a>
                  </li>
                </ul>
              </td>
            </tr>
            </tbody>
          </table>
        </div>
      </div>
    </div>
  </div>
</body>
</html>
