Springboot学习笔记（第三部分）

28、请求处理-【源码分析】-请求映射原理

SpringMVC功能分析都从 org.springframework.web.servlet.DispatcherServlet -> doDispatch()

protected void doDispatch(HttpServletRequest request, HttpServletResponse response) throws Exception {


    HttpServletRequest processedRequest = request;
    HandlerExecutionChain mappedHandler = null;
    boolean multipartRequestParsed = false;

    WebAsyncManager asyncManager = WebAsyncUtils.getAsyncManager(request);

    try {


        ModelAndView mv = null;
        Exception dispatchException = null;

        try {


            processedRequest = checkMultipart(request);
            multipartRequestParsed = (processedRequest != request);

            // 找到当前请求使用哪个Handler（Controller的方法）处理
            mappedHandler = getHandler(processedRequest);

            //HandlerMapping：处理器映射。/xxx->>xxxx
    ...
}

getHandler()方法如下：

@Nullable
protected HandlerExecutionChain getHandler(HttpServletRequest request) throws Exception {


    if (this.handlerMappings != null) {


        for (HandlerMapping mapping : this.handlerMappings) {


            HandlerExecutionChain handler = mapping.getHandler(request);
            if (handler != null) {


                return handler;
            }
        }
    }
    return null;
}

this.handlerMappings在Debug模式下展现的内容：

其中，保存了所有@RequestMapping 和handler的映射规则。

所有的请求映射都在HandlerMapping中：

• SpringBoot自动配置欢迎页的 WelcomePageHandlerMapping 。访问 /能访问到index.html；
• SpringBoot自动配置了默认 的 RequestMappingHandlerMapping

• 请求进来，挨个尝试所有的HandlerMapping看是否有请求信息。

  • 如果有就找到这个请求对应的handler
  • 如果没有就是下一个 HandlerMapping

• 我们需要一些自定义的映射处理，我们也可以自己给容器中放HandlerMapping。自定义 HandlerMapping

IDEA快捷键：

• Ctrl + Alt + U : 以UML的类图展现类有哪些继承类，派生类以及实现哪些接口。
• Crtl + Alt + Shift + U : 同上，区别在于上条快捷键结果在新页展现，而本条快捷键结果在弹窗展现。
• Ctrl + H : 以树形方式展现类层次结构图。

29、请求处理-常用参数注解使用

注解：

• @PathVariable 路径变量
• @RequestHeader 获取请求头
• @RequestParam 获取请求参数（指问号后的参数，url?a=1&b=2）
• @CookieValue 获取Cookie值
• @RequestAttribute 获取request域属性
• @RequestBody 获取请求体[POST]
• @MatrixVariable 矩阵变量
• @ModelAttribute

使用用例：

@RestController
public class ParameterTestController {




    //  car/2/owner/zhangsan
    @GetMapping("/car/{id}/owner/{username}")
    public Map<String,Object> getCar(@PathVariable("id") Integer id,
                                     @PathVariable("username") String name,
                                     @PathVariable Map<String,String> pv,
                                     @RequestHeader("User-Agent") String userAgent,
                                     @RequestHeader Map<String,String> header,
                                     @RequestParam("age") Integer age,
                                     @RequestParam("inters") List<String> inters,
                                     @RequestParam Map<String,String> params,
                                     @CookieValue("_ga") String _ga,
                                     @CookieValue("_ga") Cookie cookie){



        Map<String,Object> map = new HashMap<>();

//        map.put("id",id);
//        map.put("name",name);
//        map.put("pv",pv);
//        map.put("userAgent",userAgent);
//        map.put("headers",header);
        map.put("age",age);
        map.put("inters",inters);
        map.put("params",params);
        map.put("_ga",_ga);
        System.out.println(cookie.getName()+"===>"+cookie.getValue());
        return map;
    }


    @PostMapping("/save")
    public Map postMethod(@RequestBody String content){


        Map<String,Object> map = new HashMap<>();
        map.put("content",content);
        return map;
    }
}

30、请求处理-@RequestAttribute

用例：

@Controller
public class RequestController {



    @GetMapping("/goto")
    public String goToPage(HttpServletRequest request){



        request.setAttribute("msg","成功了...");
        request.setAttribute("code",200);
        return "forward:/success";  //转发到  /success请求
    }

    @GetMapping("/params")
    public String testParam(Map<String,Object> map,
                            Model model,
                            HttpServletRequest request,
                            HttpServletResponse response){


        map.put("hello","world666");
        model.addAttribute("world","hello666");
        request.setAttribute("message","HelloWorld");

        Cookie cookie = new Cookie("c1","v1");
        response.addCookie(cookie);
        return "forward:/success";
    }

    ///<-----------------主角@RequestAttribute在这个方法
    @ResponseBody
    @GetMapping("/success")
    public Map success(@RequestAttribute(value = "msg",required = false) String msg,
                       @RequestAttribute(value = "code",required = false)Integer code,
                       HttpServletRequest request){


        Object msg1 = request.getAttribute("msg");

        Map<String,Object> map = new HashMap<>();
        Object hello = request.getAttribute("hello");
        Object world = request.getAttribute("world");
        Object message = request.getAttribute("message");

        map.put("reqMethod_msg",msg1);
        map.put("annotation_msg",msg);
        map.put("hello",hello);
        map.put("world",world);
        map.put("message",message);

        return map;
    }
}

31、请求处理-@MatrixVariable与UrlPathHelper

1. 语法： 请求路径：/cars/sell;low=34;brand=byd,audi,yd

2. SpringBoot默认是禁用了矩阵变量的功能

   • 手动开启：原理。对于路径的处理。UrlPathHelper的removeSemicolonContent设置为false，让其支持矩阵变量的。

3. 矩阵变量必须有url路径变量才能被解析

手动开启矩阵变量：

• 实现WebMvcConfigurer接口：

@Configuration(proxyBeanMethods = false)
public class WebConfig implements WebMvcConfigurer {


    @Override
    public void configurePathMatch(PathMatchConfigurer configurer) {



        UrlPathHelper urlPathHelper = new UrlPathHelper();
        // 不移除；后面的内容。矩阵变量功能就可以生效
        urlPathHelper.setRemoveSemicolonContent(false);
        configurer.setUrlPathHelper(urlPathHelper);
    }
}

• 创建返回WebMvcConfigurerBean：

@Configuration(proxyBeanMethods = false)
public class WebConfig{


    @Bean
    public WebMvcConfigurer webMvcConfigurer(){


        return new WebMvcConfigurer() {


                        @Override
            public void configurePathMatch(PathMatchConfigurer configurer) {


                UrlPathHelper urlPathHelper = new UrlPathHelper();
                // 不移除；后面的内容。矩阵变量功能就可以生效
                urlPathHelper.setRemoveSemicolonContent(false);
                configurer.setUrlPathHelper(urlPathHelper);
            }
        }
    }
}

@MatrixVariable的用例

@RestController
public class ParameterTestController {



    ///cars/sell;low=34;brand=byd,audi,yd
    @GetMapping("/cars/{path}")
    public Map carsSell(@MatrixVariable("low") Integer low,
                        @MatrixVariable("brand") List<String> brand,
                        @PathVariable("path") String path){


        Map<String,Object> map = new HashMap<>();

        map.put("low",low);
        map.put("brand",brand);
        map.put("path",path);
        return map;
    }

    // /boss/1;age=20/2;age=10

    @GetMapping("/boss/{bossId}/{empId}")
    public Map boss(@MatrixVariable(value = "age",pathVar = "bossId") Integer bossAge,
                    @MatrixVariable(value = "age",pathVar = "empId") Integer empAge){


        Map<String,Object> map = new HashMap<>();

        map.put("bossAge",bossAge);
        map.put("empAge",empAge);
        return map;

    }

}

32、请求处理-【源码分析】-各种类型参数解析原理

这要从DispatcherServlet开始说起：

public class DispatcherServlet extends FrameworkServlet {



    protected void doDispatch(HttpServletRequest request, HttpServletResponse response) throws Exception {


        HttpServletRequest processedRequest = request;
        HandlerExecutionChain mappedHandler = null;
        boolean multipartRequestParsed = false;

        WebAsyncManager asyncManager = WebAsyncUtils.getAsyncManager(request);

        try {


            ModelAndView mv = null;
            Exception dispatchException = null;

            try {


                processedRequest = checkMultipart(request);
                multipartRequestParsed = (processedRequest != request);

                // Determine handler for the current request.
                mappedHandler = getHandler(processedRequest);
                if (mappedHandler == null) {


                    noHandlerFound(processedRequest, response);
                    return;
                }

                // Determine handler adapter for the current request.
                HandlerAdapter ha = getHandlerAdapter(mappedHandler.getHandler());
                ...

• HandlerMapping中找到能处理请求的Handler（Controller.method()）。
• 为当前Handler 找一个适配器 HandlerAdapter，用的最多的是RequestMappingHandlerAdapter。
• 适配器执行目标方法并确定方法参数的每一个值。

HandlerAdapter

默认会加载所有HandlerAdapter

public class DispatcherServlet extends FrameworkServlet {



    /** Detect all HandlerAdapters or just expect "handlerAdapter" bean?. */
    private boolean detectAllHandlerAdapters = true;

    ...

    private void initHandlerAdapters(ApplicationContext context) {


        this.handlerAdapters = null;

        if (this.detectAllHandlerAdapters) {


            // Find all HandlerAdapters in the ApplicationContext, including ancestor contexts.
            Map<String, HandlerAdapter> matchingBeans =
                BeanFactoryUtils.beansOfTypeIncludingAncestors(context, HandlerAdapter.class, true, false);
            if (!matchingBeans.isEmpty()) {


                this.handlerAdapters = new ArrayList<>(matchingBeans.values());
                // We keep HandlerAdapters in sorted order.
                AnnotationAwareOrderComparator.sort(this.handlerAdapters);
            }
        }
     ...

有这些HandlerAdapter：

1. 支持方法上标注@RequestMapping

2. 支持函数式编程的

3. ...
4. ...

执行目标方法

public class DispatcherServlet extends FrameworkServlet {



    protected void doDispatch(HttpServletRequest request, HttpServletResponse response) throws Exception {


        ModelAndView mv = null;

        ...

        // Determine handler for the current request.
        mappedHandler = getHandler(processedRequest);
        if (mappedHandler == null) {


            noHandlerFound(processedRequest, response);
            return;
        }

        // Determine handler adapter for the current request.
        HandlerAdapter ha = getHandlerAdapter(mappedHandler.getHandler());

        ...
        //本节重点
        // Actually invoke the handler.
        mv = ha.handle(processedRequest, response, mappedHandler.getHandler());

HandlerAdapter接口实现类RequestMappingHandlerAdapter（主要用来处理@RequestMapping）

public class RequestMappingHandlerAdapter extends AbstractHandlerMethodAdapter
        implements BeanFactoryAware, InitializingBean {



    ...

    //AbstractHandlerMethodAdapter类的方法，RequestMappingHandlerAdapter继承AbstractHandlerMethodAdapter
    public final ModelAndView handle(HttpServletRequest request, HttpServletResponse response, Object handler)
        throws Exception {



        return handleInternal(request, response, (HandlerMethod) handler);
    }

    @Override
    protected ModelAndView handleInternal(HttpServletRequest request,
            HttpServletResponse response, HandlerMethod handlerMethod) throws Exception {


        ModelAndView mav;
        //handleInternal的核心
        mav = invokeHandlerMethod(request, response, handlerMethod);//解释看下节
        //...
        return mav;
    }
}

参数解析器

确定将要执行的目标方法的每一个参数的值是什么;

SpringMVC目标方法能写多少种参数类型。取决于参数解析器argumentResolvers。

@Nullable
protected ModelAndView invokeHandlerMethod(HttpServletRequest request,
                                           HttpServletResponse response, HandlerMethod handlerMethod) throws Exception {



    ServletWebRequest webRequest = new ServletWebRequest(request, response);
    try {


        WebDataBinderFactory binderFactory = getDataBinderFactory(handlerMethod);
        ModelFactory modelFactory = getModelFactory(handlerMethod, binderFactory);

        ServletInvocableHandlerMethod invocableMethod = createInvocableHandlerMethod(handlerMethod);
        if (this.argumentResolvers != null) {

   //<-----关注点
            invocableMethod.setHandlerMethodArgumentResolvers(this.argumentResolvers);
        }

        ...

this.argumentResolvers在afterPropertiesSet()方法内初始化

public class RequestMappingHandlerAdapter extends AbstractHandlerMethodAdapter
        implements BeanFactoryAware, InitializingBean {



    @Nullable
    private HandlerMethodArgumentResolverComposite argumentResolvers;

    @Override
    public void afterPropertiesSet() {


        ...
        if (this.argumentResolvers == null) {

   //初始化argumentResolvers
            List<HandlerMethodArgumentResolver> resolvers = getDefaultArgumentResolvers();
            this.argumentResolvers = new HandlerMethodArgumentResolverComposite().addResolvers(resolvers);
        }
        ...
    }

    //初始化了一堆的实现HandlerMethodArgumentResolver接口的
    private List<HandlerMethodArgumentResolver> getDefaultArgumentResolvers() {


        List<HandlerMethodArgumentResolver> resolvers = new ArrayList<>(30);

        // Annotation-based argument resolution
        resolvers.add(new RequestParamMethodArgumentResolver(getBeanFactory(), false));
        resolvers.add(new RequestParamMapMethodArgumentResolver());
        resolvers.add(new PathVariableMethodArgumentResolver());
        resolvers.add(new PathVariableMapMethodArgumentResolver());
        resolvers.add(new MatrixVariableMethodArgumentResolver());
        resolvers.add(new MatrixVariableMapMethodArgumentResolver());
        resolvers.add(new ServletModelAttributeMethodProcessor(false));
        resolvers.add(new RequestResponseBodyMethodProcessor(getMessageConverters(), this.requestResponseBodyAdvice));
        resolvers.add(new RequestPartMethodArgumentResolver(getMessageConverters(), this.requestResponseBodyAdvice));
        resolvers.add(new RequestHeaderMethodArgumentResolver(getBeanFactory()));
        resolvers.add(new RequestHeaderMapMethodArgumentResolver());
        resolvers.add(new ServletCookieValueMethodArgumentResolver(getBeanFactory()));
        resolvers.add(new ExpressionValueMethodArgumentResolver(getBeanFactory()));
        resolvers.add(new SessionAttributeMethodArgumentResolver());
        resolvers.add(new RequestAttributeMethodArgumentResolver());

        // Type-based argument resolution
        resolvers.add(new ServletRequestMethodArgumentResolver());
        resolvers.add(new ServletResponseMethodArgumentResolver());
        resolvers.add(new HttpEntityMethodProcessor(getMessageConverters(), this.requestResponseBodyAdvice));
        resolvers.add(new RedirectAttributesMethodArgumentResolver());
        resolvers.add(new ModelMethodProcessor());
        resolvers.add(new MapMethodProcessor());
        resolvers.add(new ErrorsMethodArgumentResolver());
        resolvers.add(new SessionStatusMethodArgumentResolver());
        resolvers.add(new UriComponentsBuilderMethodArgumentResolver());
        if (KotlinDetector.isKotlinPresent()) {


            resolvers.add(new ContinuationHandlerMethodArgumentResolver());
        }

        // Custom arguments
        if (getCustomArgumentResolvers() != null) {


            resolvers.addAll(getCustomArgumentResolvers());
        }

        // Catch-all
        resolvers.add(new PrincipalMethodArgumentResolver());
        resolvers.add(new RequestParamMethodArgumentResolver(getBeanFactory(), true));
        resolvers.add(new ServletModelAttributeMethodProcessor(true));

        return resolvers;
    }

}

HandlerMethodArgumentResolverComposite类如下：（众多参数解析器argumentResolvers的包装类）。

public class HandlerMethodArgumentResolverComposite implements HandlerMethodArgumentResolver {



    private final List<HandlerMethodArgumentResolver> argumentResolvers = new ArrayList<>();

    ...

    public HandlerMethodArgumentResolverComposite addResolvers(
            @Nullable HandlerMethodArgumentResolver... resolvers) {



        if (resolvers != null) {


            Collections.addAll(this.argumentResolvers, resolvers);
        }
        return this;
    }

    ...
}

我们看看HandlerMethodArgumentResolver的源码：

public interface HandlerMethodArgumentResolver {



    //当前解析器是否支持解析这种参数
    boolean supportsParameter(MethodParameter parameter);

    @Nullable//如果支持，就调用 resolveArgument
    Object resolveArgument(MethodParameter parameter, @Nullable ModelAndViewContainer mavContainer,
            NativeWebRequest webRequest, @Nullable WebDataBinderFactory binderFactory) throws Exception;

}

返回值处理器

ValueHandler

@Nullable
protected ModelAndView invokeHandlerMethod(HttpServletRequest request,
                                           HttpServletResponse response, HandlerMethod handlerMethod) throws Exception {



    ServletWebRequest webRequest = new ServletWebRequest(request, response);
    try {


        WebDataBinderFactory binderFactory = getDataBinderFactory(handlerMethod);
        ModelFactory modelFactory = getModelFactory(handlerMethod, binderFactory);

        ServletInvocableHandlerMethod invocableMethod = createInvocableHandlerMethod(handlerMethod);
        if (this.argumentResolvers != null) {


            invocableMethod.setHandlerMethodArgumentResolvers(this.argumentResolvers);
        }
        if (this.returnValueHandlers != null) {

   //<---关注点
            invocableMethod.setHandlerMethodReturnValueHandlers(this.returnValueHandlers);
        }
     ...

this.returnValueHandlers在afterPropertiesSet()方法内初始化

public class RequestMappingHandlerAdapter extends AbstractHandlerMethodAdapter
        implements BeanFactoryAware, InitializingBean {



    @Nullable
    private HandlerMethodReturnValueHandlerComposite returnValueHandlers;

    @Override
    public void afterPropertiesSet() {



        ...

        if (this.returnValueHandlers == null) {


            List<HandlerMethodReturnValueHandler> handlers = getDefaultReturnValueHandlers();
            this.returnValueHandlers = new HandlerMethodReturnValueHandlerComposite().addHandlers(handlers);
        }
    }

    //初始化了一堆的实现HandlerMethodReturnValueHandler接口的
    private List<HandlerMethodReturnValueHandler> getDefaultReturnValueHandlers() {


        List<HandlerMethodReturnValueHandler> handlers = new ArrayList<>(20);

        // Single-purpose return value types
        handlers.add(new ModelAndViewMethodReturnValueHandler());
        handlers.add(new ModelMethodProcessor());
        handlers.add(new ViewMethodReturnValueHandler());
        handlers.add(new ResponseBodyEmitterReturnValueHandler(getMessageConverters(),
                this.reactiveAdapterRegistry, this.taskExecutor, this.contentNegotiationManager));
        handlers.add(new StreamingResponseBodyReturnValueHandler());
        handlers.add(new HttpEntityMethodProcessor(getMessageConverters(),
                this.contentNegotiationManager, this.requestResponseBodyAdvice));
        handlers.add(new HttpHeadersReturnValueHandler());
        handlers.add(new CallableMethodReturnValueHandler());
        handlers.add(new DeferredResultMethodReturnValueHandler());
        handlers.add(new AsyncTaskMethodReturnValueHandler(this.beanFactory));

        // Annotation-based return value types
        handlers.add(new ServletModelAttributeMethodProcessor(false));
        handlers.add(new RequestResponseBodyMethodProcessor(getMessageConverters(),
                this.contentNegotiationManager, this.requestResponseBodyAdvice));

        // Multi-purpose return value types
        handlers.add(new ViewNameMethodReturnValueHandler());
        handlers.add(new MapMethodProcessor());

        // Custom return value types
        if (getCustomReturnValueHandlers() != null) {


            handlers.addAll(getCustomReturnValueHandlers());
        }

        // Catch-all
        if (!CollectionUtils.isEmpty(getModelAndViewResolvers())) {


            handlers.add(new ModelAndViewResolverMethodReturnValueHandler(getModelAndViewResolvers()));
        }
        else {


            handlers.add(new ServletModelAttributeMethodProcessor(true));
        }

        return handlers;
    }
}

HandlerMethodReturnValueHandlerComposite类如下：

public class HandlerMethodReturnValueHandlerComposite implements HandlerMethodReturnValueHandler {



    private final List<HandlerMethodReturnValueHandler> returnValueHandlers = new ArrayList<>();

    ...

    public HandlerMethodReturnValueHandlerComposite addHandlers(
            @Nullable List<? extends HandlerMethodReturnValueHandler> handlers) {



        if (handlers != null) {


            this.returnValueHandlers.addAll(handlers);
        }
        return this;
    }

}

HandlerMethodReturnValueHandler接口：

public interface HandlerMethodReturnValueHandler {



    boolean supportsReturnType(MethodParameter returnType);

    void handleReturnValue(@Nullable Object returnValue, MethodParameter returnType,
            ModelAndViewContainer mavContainer, NativeWebRequest webRequest) throws Exception;

}

回顾执行目标方法

public class DispatcherServlet extends FrameworkServlet {


    ...
    protected void doDispatch(HttpServletRequest request, HttpServletResponse response) throws Exception {


        ModelAndView mv = null;
        ...
        mv = ha.handle(processedRequest, response, mappedHandler.getHandler());

RequestMappingHandlerAdapter的handle()方法：

public class RequestMappingHandlerAdapter extends AbstractHandlerMethodAdapter
        implements BeanFactoryAware, InitializingBean {



    ...

    //AbstractHandlerMethodAdapter类的方法，RequestMappingHandlerAdapter继承AbstractHandlerMethodAdapter
    public final ModelAndView handle(HttpServletRequest request, HttpServletResponse response, Object handler)
        throws Exception {



        return handleInternal(request, response, (HandlerMethod) handler);
    }

    @Override
    protected ModelAndView handleInternal(HttpServletRequest request,
            HttpServletResponse response, HandlerMethod handlerMethod) throws Exception {


        ModelAndView mav;
        //handleInternal的核心
        mav = invokeHandlerMethod(request, response, handlerMethod);//解释看下节
        //...
        return mav;
    }
}

RequestMappingHandlerAdapter的invokeHandlerMethod()方法：

public class RequestMappingHandlerAdapter extends AbstractHandlerMethodAdapter
        implements BeanFactoryAware, InitializingBean {



    protected ModelAndView invokeHandlerMethod(HttpServletRequest request,
            HttpServletResponse response, HandlerMethod handlerMethod) throws Exception {



        ServletWebRequest webRequest = new ServletWebRequest(request, response);
        try {


            ...

            ServletInvocableHandlerMethod invocableMethod = createInvocableHandlerMethod(handlerMethod);
            if (this.argumentResolvers != null) {


                invocableMethod.setHandlerMethodArgumentResolvers(this.argumentResolvers);
            }
            if (this.returnValueHandlers != null) {


                invocableMethod.setHandlerMethodReturnValueHandlers(this.returnValueHandlers);
            }
            ...

            //关注点：执行目标方法
            invocableMethod.invokeAndHandle(webRequest, mavContainer);
            if (asyncManager.isConcurrentHandlingStarted()) {


                return null;
            }

            return getModelAndView(mavContainer, modelFactory, webRequest);
        }
        finally {


            webRequest.requestCompleted();
        }
    }

invokeAndHandle()方法如下：

public class ServletInvocableHandlerMethod extends InvocableHandlerMethod {



    public void invokeAndHandle(ServletWebRequest webRequest, ModelAndViewContainer mavContainer,
            Object... providedArgs) throws Exception {



        Object returnValue = invokeForRequest(webRequest, mavContainer, providedArgs);

        ...

        try {


            //returnValue存储起来
            this.returnValueHandlers.handleReturnValue(
                    returnValue, getReturnValueType(returnValue), mavContainer, webRequest);
        }
        catch (Exception ex) {


            ...
        }
    }

    @Nullable//InvocableHandlerMethod类的，ServletInvocableHandlerMethod类继承InvocableHandlerMethod类
    public Object invokeForRequest(NativeWebRequest request, @Nullable ModelAndViewContainer mavContainer,
            Object... providedArgs) throws Exception {



        ////获取方法的参数值
        Object[] args = getMethodArgumentValues(request, mavContainer, providedArgs);

        ...

        return doInvoke(args);
    }

    @Nullable
    protected Object doInvoke(Object... args) throws Exception {


        Method method = getBridgedMethod();//@RequestMapping的方法
        ReflectionUtils.makeAccessible(method);
        try {


            if (KotlinDetector.isSuspendingFunction(method)) {


                return CoroutinesUtils.invokeSuspendingFunction(method, getBean(), args);
            }
            //通过反射调用
            return method.invoke(getBean(), args);//getBean()指@RequestMapping的方法所在类的对象。
        }
        catch (IllegalArgumentException ex) {


            ...
        }
        catch (InvocationTargetException ex) {


            ...
        }
    }

}

如何确定目标方法每一个参数的值

重点分析ServletInvocableHandlerMethod的getMethodArgumentValues方法

public class ServletInvocableHandlerMethod extends InvocableHandlerMethod {


    ...

    @Nullable//InvocableHandlerMethod类的，ServletInvocableHandlerMethod类继承InvocableHandlerMethod类
    public Object invokeForRequest(NativeWebRequest request, @Nullable ModelAndViewContainer mavContainer,
            Object... providedArgs) throws Exception {



        ////获取方法的参数值
        Object[] args = getMethodArgumentValues(request, mavContainer, providedArgs);

        ...

        return doInvoke(args);
    }

    //本节重点，获取方法的参数值
    protected Object[] getMethodArgumentValues(NativeWebRequest request, @Nullable ModelAndViewContainer mavContainer,
            Object... providedArgs) throws Exception {



        MethodParameter[] parameters = getMethodParameters();
        if (ObjectUtils.isEmpty(parameters)) {


            return EMPTY_ARGS;
        }

        Object[] args = new Object[parameters.length];
        for (int i = 0; i < parameters.length; i++) {


            MethodParameter parameter = parameters[i];
            parameter.initParameterNameDiscovery(this.parameterNameDiscoverer);
            args[i] = findProvidedArgument(parameter, providedArgs);
            if (args[i] != null) {


                continue;
            }
            //查看resolvers是否有支持
            if (!this.resolvers.supportsParameter(parameter)) {


                throw new IllegalStateException(formatArgumentError(parameter, "No suitable resolver"));
            }
            try {


                //支持的话就开始解析吧
                args[i] = this.resolvers.resolveArgument(parameter, mavContainer, request, this.dataBinderFactory);
            }
            catch (Exception ex) {


                ....
            }
        }
        return args;
    }

}

this.resolvers的类型为HandlerMethodArgumentResolverComposite（在参数解析器章节提及）

public class HandlerMethodArgumentResolverComposite implements HandlerMethodArgumentResolver {



    @Override
    public boolean supportsParameter(MethodParameter parameter) {


        return getArgumentResolver(parameter) != null;
    }

    @Override
    @Nullable
    public Object resolveArgument(MethodParameter parameter, @Nullable ModelAndViewContainer mavContainer,
            NativeWebRequest webRequest, @Nullable WebDataBinderFactory binderFactory) throws Exception {



        HandlerMethodArgumentResolver resolver = getArgumentResolver(parameter);
        if (resolver == null) {


            throw new IllegalArgumentException("Unsupported parameter type [" +
                    parameter.getParameterType().getName() + "]. supportsParameter should be called first.");
        }
        return resolver.resolveArgument(parameter, mavContainer, webRequest, binderFactory);
    }


    @Nullable
    private HandlerMethodArgumentResolver getArgumentResolver(MethodParameter parameter) {


        HandlerMethodArgumentResolver result = this.argumentResolverCache.get(parameter);
        if (result == null) {


            //挨个判断所有参数解析器那个支持解析这个参数
            for (HandlerMethodArgumentResolver resolver : this.argumentResolvers) {


                if (resolver.supportsParameter(parameter)) {


                    result = resolver;
                    this.argumentResolverCache.put(parameter, result);//找到了，resolver就缓存起来，方便稍后resolveArgument()方法使用
                    break;
                }
            }
        }
        return result;
    }
}

小结

本节描述，一个请求发送到DispatcherServlet后的具体处理流程，也就是SpringMVC的主要原理。

本节内容较多且硬核，对日后编程很有帮助，需耐心对待。

可以运行一个示例，打断点，在Debug模式下，查看程序流程。
