基于SpringCloud+BinLog的广告系统设计总结（二）

package com.imooc.ad;
import org.springframework.boot.SpringApplication;
import org.springframework.boot.autoconfigure.SpringBootApplication;
import org.springframework.cloud.client.circuitbreaker.EnableCircuitBreaker;
import org.springframework.cloud.client.discovery.EnableDiscoveryClient;
import org.springframework.cloud.client.loadbalancer.LoadBalanced;
import org.springframework.cloud.netflix.eureka.EnableEurekaClient;
import org.springframework.cloud.netflix.hystrix.EnableHystrix;
import org.springframework.cloud.netflix.hystrix.dashboard.EnableHystrixDashboard;
import org.springframework.cloud.openfeign.EnableFeignClients;
import org.springframework.context.annotation.Bean;
import org.springframework.web.client.RestTemplate;
@EnableFeignClients
@EnableEurekaClient
@EnableHystrix
@SpringBootApplication
public class SearchApplication {
    public static void main(String[] args) {
        SpringApplication.run(SearchApplication.class, args);
    }
    @Bean
    @LoadBalanced
    RestTemplate restTemplate() {
        return new RestTemplate();
    }
}

@IgnoreResponseAdvice
@PostMapping("/getAdPlansByRibbon")
public CommonResponse<List<AdPlan>> getAdPlansByRebbon(
            @RequestBody AdPlanGetRequest request) {
        log.info("ad-search: getAdPlansByRibbon -> {}",
                JSON.toJSONString(request));
        return restTemplate.postForEntity(
                "http://eureka-client-ad-sponsor/ad-sponsor/get/adPlan",
                request,
                CommonResponse.class
        ).getBody();
}

package com.imooc.ad.client;
import com.imooc.ad.client.vo.AdPlan;
import com.imooc.ad.client.vo.AdPlanGetRequest;
import com.imooc.ad.vo.CommonResponse;
import org.springframework.cloud.openfeign.FeignClient;
import org.springframework.web.bind.annotation.RequestBody;
import org.springframework.web.bind.annotation.RequestMapping;
import org.springframework.web.bind.annotation.RequestMethod;
import java.util.List;
@FeignClient(value = "eureka-client-ad-sponsor",
        fallback = SponsorClientHystrix.class)
public interface SponsorClient {
    @RequestMapping(value = "/ad-sponsor/get/adPlan",
            method = RequestMethod.POST)
    CommonResponse<List<AdPlan>> getAdPlans(
            @RequestBody AdPlanGetRequest request);
}

package com.imooc.ad.client;
import com.imooc.ad.client.vo.AdPlan;
import com.imooc.ad.client.vo.AdPlanGetRequest;
import com.imooc.ad.vo.CommonResponse;
import org.springframework.stereotype.Component;
import java.util.List;
@Component
public class SponsorClientHystrix implements SponsorClient {
    @Override
    public CommonResponse<List<AdPlan>> getAdPlans(
            AdPlanGetRequest request) {
        return new CommonResponse<>(-1,
                "eureka-client-ad-sponsor error");
    }
}

package com.imooc.ad.runner;
import com.imooc.ad.mysql.BinlogClient;
import lombok.extern.slf4j.Slf4j;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.boot.CommandLineRunner;
import org.springframework.stereotype.Component;
@Slf4j
@Component
public class BinlogRunner implements CommandLineRunner {
    private final BinlogClient client;
    @Autowired
    public BinlogRunner(BinlogClient client) {
        this.client = client;
    }
    @Override
    public void run(String... strings) throws Exception {
        log.info("Coming in BinlogRunner...");
        client.connect();
    }
}

package com.imooc.ad.mysql;
import com.github.shyiko.mysql.binlog.BinaryLogClient;
import com.imooc.ad.mysql.listener.AggregationListener;
import lombok.extern.slf4j.Slf4j;
import org.apache.commons.lang.StringUtils;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.stereotype.Component;
import java.io.IOException;
@Slf4j
@Component
public class BinlogClient {
    private BinaryLogClient client;
    private final BinlogConfig config;
    private final AggregationListener listener;
    @Autowired
    public BinlogClient(BinlogConfig config, AggregationListener listener) {
        this.config = config;
        this.listener = listener;
    }
    public void connect() {
        new Thread(() -> {
            client = new BinaryLogClient(
                    config.getHost(),
                    config.getPort(),
                    config.getUsername(),
                    config.getPassword()
            );
            if (!StringUtils.isEmpty(config.getBinlogName()) &&
                    !config.getPosition().equals(-1L)) {
                client.setBinlogFilename(config.getBinlogName());
                client.setBinlogPosition(config.getPosition());
            }
            client.registerEventListener(listener);
            try {
                log.info("connecting to mysql start");
                client.connect();
                log.info("connecting to mysql done");
            } catch (IOException ex) {
                ex.printStackTrace();
            }
        }).start();
    }
    public void close() {
        try {
            client.disconnect();
        } catch (IOException ex) {
            ex.printStackTrace();
        }
    }
}

package com.imooc.ad.mysql;
import lombok.AllArgsConstructor;
import lombok.Data;
import lombok.NoArgsConstructor;
import org.springframework.boot.context.properties.ConfigurationProperties;
import org.springframework.stereotype.Component;
@Component
@ConfigurationProperties(prefix = "adconf.mysql")
@Data
@NoArgsConstructor
@AllArgsConstructor
public class BinlogConfig {
    private String host;
    private Integer port;
    private String username;
    private String password;
    private String binlogName;
    private Long position;
}

package com.imooc.ad.mysql.listener;
import com.github.shyiko.mysql.binlog.BinaryLogClient;
import com.github.shyiko.mysql.binlog.event.*;
import com.imooc.ad.mysql.TemplateHolder;
import com.imooc.ad.mysql.dto.BinlogRowData;
import com.imooc.ad.mysql.dto.TableTemplate;
import lombok.extern.slf4j.Slf4j;
import org.apache.commons.lang.StringUtils;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.stereotype.Component;
import java.io.Serializable;
import java.util.*;
import java.util.stream.Collectors;
@Slf4j
@Component
public class AggregationListener implements BinaryLogClient.EventListener {
    private String dbName;
    private String tableName;
    private Map<String, Ilistener> listenerMap = new HashMap<>();
    private final TemplateHolder templateHolder;
    @Autowired
    public AggregationListener(TemplateHolder templateHolder) {
        this.templateHolder = templateHolder;
    }
    private String genKey(String dbName, String tableName) {
        return dbName + ":" + tableName;
    }
    public void register(String _dbName, String _tableName,
                         Ilistener ilistener) {
        log.info("register : {}-{}", _dbName, _tableName);
        this.listenerMap.put(genKey(_dbName, _tableName), ilistener);
    }
    @Override
    public void onEvent(Event event) {
        EventType type = event.getHeader().getEventType();
        log.debug("event type: {}", type);
        if (type == EventType.TABLE_MAP) {
            TableMapEventData data = event.getData();
            this.tableName = data.getTable();
            this.dbName = data.getDatabase();
            return;
        }
        if (type != EventType.EXT_UPDATE_ROWS
                && type != EventType.EXT_WRITE_ROWS
                && type != EventType.EXT_DELETE_ROWS) {
            return;
        }
        // 表名和库名是否已经完成填充
        if (StringUtils.isEmpty(dbName) || StringUtils.isEmpty(tableName)) {
            log.error("no meta data event");
            return;
        }
        // 找出对应表有兴趣的监听器
        String key = genKey(this.dbName, this.tableName);
        Ilistener listener = this.listenerMap.get(key);
        if (null == listener) {
            log.debug("skip {}", key);
            return;
        }
        log.info("trigger event: {}", type.name());
        try {
            BinlogRowData rowData = buildRowData(event.getData());
            if (rowData == null) {
                return;
            }
            rowData.setEventType(type);
            listener.onEvent(rowData);
        } catch (Exception ex) {
            ex.printStackTrace();
            log.error(ex.getMessage());
        } finally {
            this.dbName = "";
            this.tableName = "";
        }
    }
    private List<Serializable[]> getAfterValues(EventData eventData) {
        if (eventData instanceof WriteRowsEventData) {
            return ((WriteRowsEventData) eventData).getRows();
        }
        if (eventData instanceof UpdateRowsEventData) {
            return ((UpdateRowsEventData) eventData).getRows().stream()
                    .map(Map.Entry::getValue)
                    .collect(Collectors.toList());
        }
        if (eventData instanceof DeleteRowsEventData) {
            return ((DeleteRowsEventData) eventData).getRows();
        }
        return Collections.emptyList();
    }
    private BinlogRowData buildRowData(EventData eventData) {
        TableTemplate table = templateHolder.getTable(tableName);
        if (null == table) {
            log.warn("table {} not found", tableName);
            return null;
        }
        List<Map<String, String>> afterMapList = new ArrayList<>();
        for (Serializable[] after : getAfterValues(eventData)) {
            Map<String, String> afterMap = new HashMap<>();
            int colLen = after.length;
            for (int ix = 0; ix < colLen; ++ix) {
                // 取出当前位置对应的列名
                String colName = table.getPosMap().get(ix);
                // 如果没有则说明不关心这个列
                if (null == colName) {
                    log.debug("ignore position: {}", ix);
                    continue;
                }
                String colValue = after[ix].toString();
                afterMap.put(colName, colValue);
            }
            afterMapList.add(afterMap);
        }
        BinlogRowData rowData = new BinlogRowData();
        rowData.setAfter(afterMapList);
        rowData.setTable(table);
        return rowData;
    }
}
