# 查看nginx进程
[root@VM-0-7-centos artisan_ng]# ps -ef|grep nginx |grep -v grep
root 447751 1 0 12:23 ? 00:00:00 nginx: master process ./nginx -c /root/ng/artisan_ng/conf/nginx.conf
nobody 454927 447751 0 13:14 ? 00:00:00 nginx: worker process
[root@VM-0-7-centos artisan_ng]#
[root@VM-0-7-centos artisan_ng]# pwd
/root/ng/artisan_ng
[root@VM-0-7-centos artisan_ng]# ls
client_body_temp conf fastcgi_temp html logs proxy_temp sbin scgi_temp uwsgi_temp
[root@VM-0-7-centos artisan_ng]# cd sbin/
# 模拟 上传新版本,老版本的ng备份
[root@VM-0-7-centos sbin]# cp nginx nginx_old
[root@VM-0-7-centos sbin]#
# 发送 USR2 信号给 原来的ng的 pid
[root@VM-0-7-centos sbin]# kill -USR2 447751
[root@VM-0-7-centos sbin]#
# 再次查看ng进程,会发现多出来几个, 此时老的ng已经不再监听了,流量会切到新的ng上来
[root@VM-0-7-centos sbin]# ps -ef|grep nginx
root 447751 1 0 12:23 ? 00:00:00 nginx: master process ./nginx -c /root/ng/artisan_ng/conf/nginx.conf
nobody 454927 447751 0 13:14 ? 00:00:00 nginx: worker process
root 455372 447751 0 13:17 ? 00:00:00 nginx: master process ./nginx -c /root/ng/artisan_ng/conf/nginx.conf
nobody 455373 455372 0 13:17 ? 00:00:00 nginx: worker process
root 455386 454554 0 13:17 pts/1 00:00:00 grep --color=auto nginx
[root@VM-0-7-centos sbin]#
[root@VM-0-7-centos sbin]#
# 向老的ng master 发送信息,优雅的关闭它的 work线程 (需要等待老业务都处理完了)
[root@VM-0-7-centos sbin]# kill -WINCH 447751
[root@VM-0-7-centos sbin]#
[root@VM-0-7-centos sbin]#
# 老的master进程 还是存在的, 已经没有work进程了 。 老的ngxin存在 便于我们进行版本回退 (可以给老的nginx 发送 reload命令)
[root@VM-0-7-centos sbin]# ps -ef|grep nginx |grep -v grep
root 447751 1 0 12:23 ? 00:00:00 nginx: master process ./nginx -c /root/ng/artisan_ng/conf/nginx.conf
root 455372 447751 0 13:17 ? 00:00:00 nginx: master process ./nginx -c /root/ng/artisan_ng/conf/nginx.conf
nobody 455373 455372 0 13:17 ? 00:00:00 nginx: worker process
[root@VM-0-7-centos sbin]#
[root@VM-0-7-centos sbin]#
