附录B“启动后第一条执行的指令”
附录B“启动后第一条执行的指令”
intel 资料的说明
【参考 IA-32 Intel Architecture Software Developer’s Manual Volume 3: System Programming Guide Section 9.1.4】
9.1.4 First Instruction Executed
The first instruction that is fetched and executed following a hardware reset is located at physical address FFFFFFF0H. This address is 16 bytes below the processor’s uppermost physical address. The EPROM containing the softwareinitialization code must be located at this address.
The address FFFFFFF0H is beyond the 1-MByte addressable range of the processor while in real-address mode. The processor is initialized to this starting address as follows. The CS register has two parts: the visible segment selector part and the hidden base address part. In real-address mode, the base address is normally formed by shifting the 16-bit segment selector value 4 bits to the left to produce a 20-bit base address. However, during a hardware reset, the segment selector in the CS register is loaded with F000H and the base address is loaded with FFFF0000H. The starting address is thus formed by adding the base address to the value in the EIP register (that is, FFFF0000 + FFF0H = FFFFFFF0H).
The first time the CS register is loaded with a new value after a hardware reset, the processor will follow the normal rule for address translation in real-address mode (that is, [CS base address = CS segment selector * 16]). To insure that the base address in the CS register remains unchanged until the EPROM based softwareinitialization code is completed, the code must not contain a far jump or far call or allow an interrupt to occur (which would cause the CS selector value to be changed).
单步调试和查看 BIOS 代码
如果你是想看 BIOS 的汇编，可试试如下方法： 练习 2 可以单步跟踪，方法如下：
1 修改 lab1/tools/gdbinit,
set architecture i8086 target remote :1234
2 在 lab1 目录下，执行
make debug
这时 gdb 停在 BIOS 的第一条指令处：
0xffff0: ljmp $0xf000,$0xe05b
3 在看到 gdb 的调试界面(gdb)后，执行如下命令，就可以看到 BIOS 在执行了
si si ...
4 此时的CS=0xf000, EIP=0xfff0，如果想看 BIOS 的代码
x /2i 0xffff0
应该可以看到
0xffff0: ljmp $0xf000,$0xe05b 0xffff5: xor %dh,0x322f
进一步可以执行
x /10i 0xfe05b
可以看到后续的 BIOS 代码。
