问题
我们经常看到网上的在线工具里有RGB颜色值与十六进制颜色码转换工具,那么这个是怎么实现的呢?
实现
rgb(255, 255, 255) => "#" + "FF" + "FF" + "FF"; "#" + "FF" + "FF" + "FF" => rgb(255, 255, 255);
可以理解为 FF0000 + FF00 + FF,如果左移是基于十六进制计算的,则可以理解为FF << 4,FF << 2,FF。
<!DOCTYPE html> <html lang="en"> <head> <meta charset="UTF-8" /> <meta http-equiv="X-UA-Compatible" content="IE=edge" /> <meta name="viewport" content="width=device-width, initial-scale=1.0" /> <title>RGB颜色值与十六进制颜色码转换</title> <style> input { width: 100px; } .hex-color,.rgb-color { width: 100px; height: 100px; border: 1px solid salmon; } </style> </head> <body> <h1>kaimo 测试</h1> <div> <h3>RGB颜色值转换成十六进制颜色码:</h3> <div> <input type="text" name="rgbNum" value="0" maxlength="3"> <input type="text" name="rgbNum" value="0" maxlength="3"> <input type="text" name="rgbNum" value="0" maxlength="3"> <button onclick="hexAdecimalColorCode()">转换</button> </div> <div> <h4> 转换后的十六进制颜色码:<span class="hex-code"></span> </h4> <div class="hex-color"></div> </div> </div> <div> <h3>十六进制颜色码转换成RGB颜色值:</h3> <div> <input type="text" name="hexStr" value="#000000"> <button onclick="rgbColorCode()">转换</button> </div> <div> <h4> 转换后的RGB颜色码:<span class="rgb-code"></span> </h4> <div class="rgb-color"></div> </div> </div> <script> function hexAdecimalColorCode() { let rgbNumDom = document.getElementsByName("rgbNum"); let arr = []; for (let i = 0; i < 3; i++) { let rn = rgbNumDom[i].value; if (isNaN(parseInt(rn))) { return alert("请输入数字"); } else if(parseInt(rn) > 255 || parseInt(rn) < 0) { return alert("数字在0-255之间"); } arr.push(rn); } if(arr.length !== 3) { return alert("RGB颜色值不合法"); } // 核心转换为16进制的操作 let hexStr = (arr[0] << 16 | arr[1] << 8 | arr[2]).toString(16); // 补零 if(hexStr.length < 6) { hexStr = `0${new Array((6 - hexStr.length)).join("0")}${hexStr}`; console.log("进入补零:", hexStr); } let hexCode = `#${hexStr}`; document.querySelector(".hex-code").innerHTML = hexCode; document.querySelector(".hex-color").style.backgroundColor = hexCode; return hexCode; } function rgbColorCode() { let hs = document.getElementsByName("hexStr")[0].value; if (hs.substr(0, 1) === "#"){ hs = hs.substring(1); if (hs.length !== 3 && hs.length !== 6){ return alert("十六进制颜色码为三位或六位"); } else if (/[^0-9a-f]/i.test(hs)){ return alert("请输入正确的十六进制颜色码"); } } else { return alert("十六进制颜色码不合法"); } let hsArr = hs.toLowerCase().split(""); console.log("hsArr--->", hsArr); let arr = []; if(hs.length === 3) { // 十六进制转为十进制 arr = hsArr.map(el => parseInt((el + el), 16)); console.log("arr--->", arr); } else { const [a, b, c, d, e, f] = hsArr; arr = [a + b, c + d, e + f].map(el => parseInt(el, 16)); console.log("arr--6-->", arr); } let rgbCode = `rgb(${arr.join(",")})`; console.log(rgbCode); document.querySelector(".rgb-code").innerHTML = rgbCode; document.querySelector(".rgb-color").style.backgroundColor = rgbCode; return rgbCode; } </script> </body> </html>
效果如下:
