由于spring4+支持泛型，这个特性对通用Mapper来说，非常的有用，可以说有了这个特性我们就可以继承通用的Mapper<T>实现crud的操作，节省了我们开发的时间。

以往我们使用mapper文件都是自己写sql语句，针对的是单个实体，也就是每个实体都有其对应的mapper文件。使用通用mapper给我们带来了极大的方便，通用mapper里面有许多我们常用的接口，平时开发90%的crud操作都在里面，只需我们调用相应的接口，引入jar包再进行简单的配置就好了。

这是一位大佬的开源项目，想学习的可以去他的github点击打开链接

这里我整合了一个springmvc的通用mapper例子

首先在pom.xml中添加对通用mapper的支持，其他的和springmvc一致

        <!--通用Mapper-->
        <dependency>
            <groupId>tk.mybatis</groupId>
            <artifactId>mapper</artifactId>
            <version>${mapper.version}</version>
        </dependency>

插件配置

            <plugin>
                <groupId>org.mybatis.generator</groupId>
                <artifactId>mybatis-generator-maven-plugin</artifactId>
                <version>1.3.6</version>
                <configuration>
                    <configurationFile>${basedir}/src/main/resources/generator/generatorConfig.xml</configurationFile>
                    <overwrite>true</overwrite>
                    <verbose>true</verbose>
                </configuration>
                <dependencies>
                    <dependency>
                        <groupId>mysql</groupId>
                        <artifactId>mysql-connector-java</artifactId>
                        <version>${mysql.version}</version>
                    </dependency>
                    <dependency>
                        <groupId>tk.mybatis</groupId>
                        <artifactId>mapper</artifactId>
                        <version>${mapper.version}</version>
                    </dependency>
                </dependencies>
            </plugin>

通用 Mapper 支持 MyBatis 3.2.4+，我这里用的mybatis版本是3.4.6,spring的版本是4.1.2，mybatis.spring的版本是1.3.1，mapper的版本是4.0.0

如果版本不匹配的话会出现错误如下

错误org.mybatis.spring.transaction.SpringManagedTransaction.getTimeout()Ljava/lang/Integer;

解决方法：更换Spring_Mybatis整合包版本，具体版本对照如下

MyBatis-Spring	MyBatis	Spring
1.0.0 and 1.0.1	3.0.1 to 3.0.5	3.0.0 or higher

1.0.2	3.0.6	3.0.0 or higher
1.1.0 or higher	3.1.0 or higher	3.0.0 or higher
1.3.0 or higher	3.4.0 or higher	3.0.0 or higher

项目结构图

1.web.xml配置

<?xml version="1.0" encoding="UTF-8"?>
<web-app xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
  xmlns="http://java.sun.com/xml/ns/javaee"
  xsi:schemaLocation="http://java.sun.com/xml/ns/javaee http://java.sun.com/xml/ns/javaee/web-app_3_0.xsd"
  id="WebApp_ID1" version="3.0">
  <context-param>
    <param-name>contextConfigLocation</param-name>
    <param-value>classpath:spring-mybatis.xml</param-value>
  </context-param>
  <filter>
    <description>字符集过滤器</description>
    <filter-name>encodingFilter</filter-name>
    <filter-class>org.springframework.web.filter.CharacterEncodingFilter</filter-class>
    <init-param>
      <description>字符集编码</description>
      <param-name>encoding</param-name>
      <param-value>UTF-8</param-value>
    </init-param>
  </filter>
  <filter-mapping>
    <filter-name>encodingFilter</filter-name>
    <url-pattern>/*</url-pattern>
  </filter-mapping>
  <listener>
    <description>spring监听器</description>
    <listener-class>org.springframework.web.context.ContextLoaderListener</listener-class>
  </listener>
  <listener>
    <listener-class>org.springframework.web.util.IntrospectorCleanupListener</listener-class>
  </listener>
  <servlet>
    <description>spring mvc servlet</description>
    <servlet-name>springMvc</servlet-name>
    <servlet-class>org.springframework.web.servlet.DispatcherServlet</servlet-class>
    <init-param>
      <description>spring mvc 配置文件</description>
      <param-name>contextConfigLocation</param-name>
      <param-value>classpath:spring-mvc.xml</param-value>
    </init-param>
    <load-on-startup>1</load-on-startup>
  </servlet>
  <servlet-mapping>
    <servlet-name>springMvc</servlet-name>
    <url-pattern>/</url-pattern>
  </servlet-mapping>
    <servlet-mapping>
    <servlet-name>default</servlet-name>
    <url-pattern>*.jpg</url-pattern>
  </servlet-mapping>
  <servlet-mapping>
    <servlet-name>default</servlet-name>
    <url-pattern>*.js</url-pattern>
  </servlet-mapping>
  <servlet-mapping>
    <servlet-name>default</servlet-name>
    <url-pattern>*.css</url-pattern>
  </servlet-mapping>
  <servlet-mapping>
    <servlet-name>default</servlet-name>
    <url-pattern>*.png</url-pattern>
  </servlet-mapping>
  <servlet-mapping>
    <servlet-name>default</servlet-name>
    <url-pattern>*.gif</url-pattern>
  </servlet-mapping>
  <servlet-mapping>
    <servlet-name>default</servlet-name>
    <url-pattern>*.html</url-pattern>
  </servlet-mapping>
  <welcome-file-list>
    <welcome-file>/index.jsp</welcome-file>
  </welcome-file-list>
  <session-config>
    <session-timeout>60</session-timeout>
  </session-config>
</web-app>

2.spring-mybatis.xml配置

<?xml version="1.0" encoding="UTF-8"?>
<beans xmlns="http://www.springframework.org/schema/beans"
  xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:tx="http://www.springframework.org/schema/tx"
  xmlns:aop="http://www.springframework.org/schema/aop" xmlns:context="http://www.springframework.org/schema/context"
  xsi:schemaLocation="
http://www.springframework.org/schema/beans
http://www.springframework.org/schema/beans/spring-beans.xsd
http://www.springframework.org/schema/tx
http://www.springframework.org/schema/tx/spring-tx.xsd
http://www.springframework.org/schema/aop
http://www.springframework.org/schema/aop/spring-aop.xsd
http://www.springframework.org/schema/context
http://www.springframework.org/schema/context/spring-context.xsd
">
  <!-- Spring:配置扫描容器，不扫描Controller和ControllerAdvice注解 -->
  <context:component-scan base-package="com.smxy.lq">
    <context:exclude-filter type="annotation"
      expression="org.springframework.stereotype.Controller" />
    <context:exclude-filter type="annotation"
      expression="org.springframework.web.bind.annotation.ControllerAdvice" />
  </context:component-scan>
  <!-- 引入属性文件 -->
  <context:property-placeholder location="classpath:config.properties" />
  <!-- 配置数据源 -->
  <bean name="dataSource" class="com.alibaba.druid.pool.DruidDataSource"
    init-method="init" destroy-method="close">
    <property name="url" value="${jdbc.url}" />
    <property name="username" value="${jdbc.username}" />
    <property name="password" value="${jdbc.password}" />
    <!-- 初始化连接大小 -->
    <property name="initialSize" value="0" />
    <!-- 连接池最大使用连接数量 -->
    <property name="maxActive" value="20" />
    <!-- 连接池最大空闲 -->
    <property name="maxIdle" value="20" />
    <!-- 连接池最小空闲 -->
    <property name="minIdle" value="0" />
    <!-- 获取连接最大等待时间 -->
    <property name="maxWait" value="60000" />
    <property name="validationQuery" value="${validationQuery}" />
    <property name="testOnBorrow" value="false" />
    <property name="testOnReturn" value="false" />
    <property name="testWhileIdle" value="true" />
    <!-- 配置间隔多久才进行一次检测，检测需要关闭的空闲连接，单位是毫秒 -->
    <property name="timeBetweenEvictionRunsMillis" value="60000" />
    <!-- 配置一个连接在池中最小生存的时间，单位是毫秒 -->
    <property name="minEvictableIdleTimeMillis" value="25200000" />
    <!-- 打开removeAbandoned功能 -->
    <property name="removeAbandoned" value="true" />
    <!-- 1800秒，也就是30分钟 -->
    <property name="removeAbandonedTimeout" value="1800" />
    <!-- 关闭abanded连接时输出错误日志 -->
    <property name="logAbandoned" value="true" />
    <!-- 监控数据库 -->
    <!-- <property name="filters" value="stat" /> -->
    <property name="filters" value="mergeStat" />
  </bean>
  <!-- MyBatis配置 这个就是spring和mybatis的整合 也就是spring-mybatis jar -->
  <bean id="sqlSessionFactory" class="org.mybatis.spring.SqlSessionFactoryBean">
    <!--数据库的数据源配置 -->
    <property name="dataSource" ref="dataSource" />
    <!-- mysqlSqlSessionFactory会自动扫描该路径下的所有文件并解析。 -->
    <property name="mapperLocations" value="classpath:mapper/*.xml" />
    <!-- 自动扫描entity目录, 省掉Configuration.xml里的手工配置 ，该属性可以给包中的类注册别名，注册后可以直接使用类名，而不用使用全限定的类名 -->
    <property name="typeAliasesPackage" value="com.smxy.lq.pojo" />
  </bean>
  <!--在Spring中配置Mapper接口 -->
  <bean class="tk.mybatis.spring.mapper.MapperScannerConfigurer">
    <!-- 为映射器接口文件设置基本的包路径 -->
    <property name="basePackage" value="com.smxy.lq.mapper" />
  </bean>
  <bean id="sqlSession" class="org.mybatis.spring.SqlSessionTemplate"
    scope="prototype">
    <constructor-arg index="0" ref="sqlSessionFactory" />
  </bean>
  <!-- 配置事务管理器 -->
  <bean id="transactionManager"
    class="org.springframework.jdbc.datasource.DataSourceTransactionManager">
    <property name="dataSource" ref="dataSource" />
  </bean>
  <!-- 注解方式配置事物 -->
  <!-- <tx:annotation-driven transaction-manager="transactionManager" /> -->
  <!-- 拦截器方式配置事物 -->
  <tx:advice id="transactionAdvice" transaction-manager="transactionManager">
    <tx:attributes>
      <tx:method name="add*" propagation="REQUIRED" />
      <tx:method name="append*" propagation="REQUIRED" />
      <tx:method name="insert*" propagation="REQUIRED" />
      <tx:method name="save*" propagation="REQUIRED" />
      <tx:method name="update*" propagation="REQUIRED" />
      <tx:method name="modify*" propagation="REQUIRED" />
      <tx:method name="edit*" propagation="REQUIRED" />
      <tx:method name="delete*" propagation="REQUIRED" />
      <tx:method name="remove*" propagation="REQUIRED" />
      <tx:method name="repair" propagation="REQUIRED" />
      <tx:method name="delAndRepair" propagation="REQUIRED" />
      <tx:method name="get*" propagation="SUPPORTS" />
      <tx:method name="find*" propagation="SUPPORTS" />
      <tx:method name="load*" propagation="SUPPORTS" />
      <tx:method name="search*" propagation="SUPPORTS" />
      <tx:method name="datagrid*" propagation="SUPPORTS" />
      <tx:method name="*" propagation="SUPPORTS" />
    </tx:attributes>
  </tx:advice>
  <aop:config>
    <aop:pointcut id="transactionPointcut"
      expression="execution(* com.smxy.lq.service..*Impl.*(..))" />
    <aop:advisor pointcut-ref="transactionPointcut"
      advice-ref="transactionAdvice" />
  </aop:config>
  <!-- 配置druid监控spring jdbc -->
  <bean id="druid-stat-interceptor"
    class="com.alibaba.druid.support.spring.stat.DruidStatInterceptor">
  </bean>
  <bean id="druid-stat-pointcut" class="org.springframework.aop.support.JdkRegexpMethodPointcut"
    scope="prototype">
    <property name="patterns">
      <list>
        <value>com.smxy.lq.service.*</value>
        <value>com.smxy.lq.serviceimpl.*</value>
      </list>
    </property>
  </bean>
  <aop:config>
    <aop:advisor advice-ref="druid-stat-interceptor"
      pointcut-ref="druid-stat-pointcut" />
  </aop:config>
</beans>

3.spring-mvc配置

<?xml version="1.0" encoding="UTF-8"?>
<beans xmlns="http://www.springframework.org/schema/beans"
  xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:context="http://www.springframework.org/schema/context"
  xmlns:mvc="http://www.springframework.org/schema/mvc"
  xsi:schemaLocation="http://www.springframework.org/schema/beans
  http://www.springframework.org/schema/beans/spring-beans.xsd
  http://www.springframework.org/schema/context
  http://www.springframework.org/schema/context/spring-context.xsd
  http://www.springframework.org/schema/mvc
  http://www.springframework.org/schema/mvc/spring-mvc.xsd">
  <!-- 1.SpringMvc:配置容器扫描只扫描Controller注解和ControllerAdvice注解 -->
  <context:component-scan base-package="com.smxy.lq"
    use-default-filters="false">
    <context:include-filter type="annotation"
      expression="org.springframework.stereotype.Controller" />
    <context:include-filter type="annotation"
      expression="org.springframework.web.bind.annotation.ControllerAdvice" />
  </context:component-scan>
  <!-- 2.配置视图解析器 -->
  <bean
    class="org.springframework.web.servlet.view.InternalResourceViewResolver">
    <property name="prefix" value="/"></property>
    <property name="suffix" value=".jsp"></property>
  </bean>
  <!-- 3.处理静态资源 -->
  <mvc:default-servlet-handler />
  <mvc:annotation-driven></mvc:annotation-driven>
  <!-- 4.文件上传,配置MultipartResolver 使用spring的CommosMultipartResolver -->
  <bean id="multipartResolver"
    class="org.springframework.web.multipart.commons.CommonsMultipartResolver">
    <!-- 设置上传文件的最大尺寸为5MB -->
    <property name="maxUploadSize">
      <value>5242880</value>
    </property>
  </bean>
  <!-- 5.全局异常处理器 只要实现HandlerExceptionResolver接口就是全局异常处理器 -->
  <!-- <bean class="com.smxy.study.exception.ErrorExceptionResolver"></bean> -->
</beans>

4.generatorConfig.xml配置，可以产生代码的工具，之前有一篇博客上介绍如何使用地址：点击打开链接

<?xml version="1.0" encoding="UTF-8"?>
<!DOCTYPE generatorConfiguration
        PUBLIC "-//mybatis.org//DTD MyBatis Generator Configuration 1.0//EN"
        "http://mybatis.org/dtd/mybatis-generator-config_1_0.dtd">
<generatorConfiguration>
    <properties resource="config.properties"/>
    <context id="Mysql" targetRuntime="MyBatis3Simple" defaultModelType="flat">
        <property name="beginningDelimiter" value="`"/>
        <property name="endingDelimiter" value="`"/>
        <plugin type="tk.mybatis.mapper.generator.MapperPlugin">
            <property name="mappers" value="tk.mybatis.mapper.common.Mapper"/>
            <property name="caseSensitive" value="true"/>
        </plugin>
        <jdbcConnection driverClass="${jdbc.driverClass}"
                        connectionURL="${jdbc.url}"
                        userId="${jdbc.user}"
                        password="${jdbc.password}">
        </jdbcConnection>
        <javaModelGenerator targetPackage="com.smxy.lq.pojo" targetProject="src/main/java"/>
        <sqlMapGenerator targetPackage="mapper" targetProject="src/main/resources"/>
        <javaClientGenerator targetPackage="com.smxy.lq.mapper" targetProject="src/main/java"
                             type="XMLMAPPER"/>
        <table tableName="country">
            <generatedKey column="id" sqlStatement="JDBC"/>
        </table>
    </context>
</generatorConfiguration>

产生完的mapper都会继承Mapper这个接口，这个Mapper接口里面有需要我们常用的crud方法,这里面可以什么都不要写，只要在Service里面写上方法就行了。

5.Service里面写上自定义方法

package com.smxy.lq.service;
import com.smxy.lq.pojo.Country;
public interface CountryService {
  // 查找
  public Country findCountryById(Integer id) throws Exception;
  // 删除
  public void delectCountryById(Integer id) throws Exception;
  // 插入
  public void insertCountry(Country country) throws Exception;
  // 修改
  public void updateCountry(Country country) throws Exception;
}

6.实现类重写该方法，并注入mapper，使用通用mapper方法实现crud操作，通用方法有很多，可自行尝试，我这里只有简单的增删改查四个

7.在controller层使用

package com.smxy.lq.controller;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.stereotype.Controller;
import org.springframework.web.bind.annotation.RequestMapping;
import org.springframework.web.bind.annotation.ResponseBody;
import org.springframework.web.servlet.ModelAndView;
import com.smxy.lq.pojo.Country;
import com.smxy.lq.service.CountryService;
@Controller
public class CountryController {
  @Autowired
  CountryService countryService;
  @RequestMapping("/findcountry")
  public @ResponseBody Country findcountry() throws Exception{
    return countryService.findCountryById(1);
  }
  @RequestMapping("/delectCountryById")
  public  void delectCountryById() throws Exception{
    countryService.delectCountryById(1);
  }
  @RequestMapping("/insertCountry")
  public  void insertCountry() throws Exception{
    Country country=new Country();
    country.setCountryname("asdfasdf");
    country.setCountrycode("asdfasdf");
    countryService.insertCountry(country);
  }
  @RequestMapping("/updateCountry")
  public  void updateCountry() throws Exception{
    Country country=new Country();
    country.setId(3);
    country.setCountryname("asdfasdf");
    country.setCountrycode("asdfasdf");
    countryService.updateCountry(country);
  }
}

spring整合通用mapper

热门文章

最新文章

相关课程

相关电子书

相关实验场景
