kubernetes 的TCP 数据包可视化

介绍

k8spacket是用 Golang 编写的工具，它使用gopacket第三方库来嗅探工作负载（传入和传出）上的 TCP 数据包。它在运行的容器网络接口上创建 TCP 侦听器。当 Kubernetes 创建一个新容器时，CNI 插件负责提供与其他容器进行通信的可能性。最常见的方法是用linux namespace隔离网络并用veth pair连接隔离的 namespace 与网桥。除了bridge 类型，CNI 插件还可以使用其他类型（vlan, ipvlan,macvlan)，但都为容器创建了一个网络接口，它是k8spacket嗅探器的主要句柄。

k8spacket有助于了解 Kubernetes 集群中的 TCP 数据包流量：

显示集群中工作负载之间的流量
通知流量在集群外路由到哪里
显示有关连接关闭套接字的信息
显示工作负载发送/接收的字节数
计算建立连接的时间
显示整个集群中工作负载之间的网络连接拓扑

k8spacket是一个 Kubernetes API 客户端，可以将嗅探到的工作负载解析为可视化上可见的集群资源名称（Pods和Services）。它作为DaemonSet Pod启动，使用 hostNetwork，并监听节点上的网络接口。

k8spacket 收集 TCP 流、处理数据，使用 Node Graph API Grafana 数据源插件（详情请查看 Node Graph API 插件），通过 API 展示在Grafana面板。

要安装k8spacket，需要同时安装 Grafana。下面将在Kind安装的 k8s 集群上做演示。

添加 k8spacket 的helm源

[root@k8s-master-1 ~]# helm repo add k8spacket https://k8spacket.github.io/k8spacket-helm-chart
"k8spacket" has been added to your repositories
[root@k8s-master-1 ~]#
[root@k8s-master-1 ~]#
[root@k8s-master-1 ~]#
[root@k8s-master-1 ~]# helm install k8spacket --namespace k8spacket k8spacket/k8spacket --create-namespace
NAME: k8spacket
LAST DEPLOYED: Thu Oct 27 18:48:30 2022
NAMESPACE: k8spacket
STATUS: deployed
REVISION: 1
TEST SUITE: None
NOTES:
1. Get the application URL by running these commands:
  export NODE_PORT=$(kubectl get --namespace k8spacket -o jsonpath="{.spec.ports[0].nodePort}" services k8spacket)
  export NODE_IP=$(kubectl get nodes --namespace k8spacket -o jsonpath="{.items[0].status.addresses[0].address}")
  echo http://$NODE_IP:$NODE_PORT
[root@k8s-master-1 ~]#

查看 pod 信息

root@hello:~# kubectl  get pod -n k8spacket
NAME              READY   STATUS             RESTARTS      AGE
k8spacket-46587   0/1     CrashLoopBackOff   2 (23s ago)   2m24s
k8spacket-9wb5q   0/1     CrashLoopBackOff   1 (6s ago)    2m24s
k8spacket-grh7k   0/1     ImagePullBackOff   0             2m24s
k8spacket-hcgg4   0/1     CrashLoopBackOff   1 (4s ago)    2m24s
k8spacket-ng99p   0/1     CrashLoopBackOff   1 (3s ago)    2m24s
k8spacket-p7hgb   0/1     CrashLoopBackOff   1 (4s ago)    2m24s
k8spacket-pk4zt   0/1     CrashLoopBackOff   1 (4s ago)    2m24s
k8spacket-tcksl   0/1     CrashLoopBackOff   1 (6s ago)    2m24s
k8spacket-tkzcc   0/1     CrashLoopBackOff   1 (8s ago)    2m24s
k8spacket-w8r5r   0/1     CrashLoopBackOff   3 (11s ago)   2m24s
root@hello:~#

查看报错为 tunl0 问题

[root@k8s-master-1 ~]# kubectl logs -n k8spacket k8spacket-46587
2022/10/27 13:35:36 Serving requests on port 6676
2022/10/27 13:35:36 Refreshing interfaces for capturing...
2022/10/27 13:35:36 Starting capture on interface "cilium_host"
2022/10/27 13:35:36 Starting capture on interface "tunl0"
2022/10/27 13:35:36 Starting capture on interface "lxc_health"
2022/10/27 13:35:36 Starting capture on interface "cilium_net"
2022/10/27 13:35:36 Starting capture on interface "lxcaaf84592af2d"
2022/10/27 13:35:36 Starting capture on interface "lxcc06519232b44"
2022/10/27 13:35:36 reading in packets
2022/10/27 13:35:36 reading in packets
2022/10/27 13:35:36 error opening pcap handle: tunl0: That device is not up
[root@k8s-master-1 ~]#

修改配置

# 将 charts 包拉取到本地 在进行修改信息
[root@k8s-master-1 ~]# cd /tmp/
[root@k8s-master-1 tmp]# helm fetch k8spacket/k8spacket
[root@k8s-master-1 tmp]# tar -zxf k8spacket-0.1.3.tgz
[root@k8s-master-1 tmp]# cd k8spacket


# 设置配置为
command: "ip address | grep @  | grep -v tunl0 | sed -E 's/.* (\\w+)@.*/\\1/' | tr '\\n' ',' | sed 's/.$//'"

# 完整配置如下
[root@k8s-master-1 k8spacket]# vim values.yaml
[root@k8s-master-1 k8spacket]# cat values.yaml
replicaCount: 1

affinity: {}

image:
  repository: docker.io/k8spacket/k8spacket
  pullPolicy: IfNotPresent

serviceAccount:
  create: true
  # Annotations to add to the service account
  annotations: {}

clusterRole:
  create: true

nodeSelector: {}

podAnnotations: {}

priorityClassName: ""

podSecurityContext:
  runAsUser: 1000

securityContext:
  allowPrivilegeEscalation: true
  capabilities:
    add: [ "NET_ADMIN", "NET_RAW" ]

service:
  type: ClusterIP
  port: 8080
  nodePort:

resources:
  requests:
    memory: "1000Mi"
    cpu: "250m"
  limits:
    memory: "1500Mi"
    cpu: "500m"

tolerations: []

k8sPacket:
  metrics:
    ## Hide source port when 'true' (set to string value 'dynamic' instead of decimal real source port) for Prometheus metrics cardinality reasons
    hideSourcePort: true
    reverseLookup:
      ## Reverse lookup db file based on GeoLite2 Free Geolocation Data
      ## See: https://dev.maxmind.com/geoip/geolite2-free-geolocation-data?lang=en
      geoipDBPath: "/home/k8spacket/GeoLite2-City.mmdb"
      ## Whois result match regexp
      whoisRegexp: "(?:OrgName:|org-name:)\\s*(.*)"
  tcp:
    listener:
      port: 6676
      interfaces:
        ## Command to achieve containers network interfaces
        command: "ip address | grep @  | grep -v tunl0 | sed -E 's/.* (\\w+)@.*/\\1/' | tr '\\n' ',' | sed 's/.$//'"
        ## How often refresh the list of network interfaces to listen
        refreshPeriod: "10s"
    assembler:
      ## See: https://pkg.go.dev/github.com/google/gopacket/tcpassembly#AssemblerOptions
      maxPagesPerConnection: 50
      maxPagesTotal: 50
      ## Every (periodDuration) seconds, flush connections that haven't seen activity in the past (closeOlderThanDuration) seconds.
      flushing:
        periodDuration: "10s"
        closeOlderThanDuration: "20s"
[root@k8s-master-1 k8spacket]#

重新安装 k8spacket

[root@k8s-master-1 k8spacket]# helm uninstall k8spacket -n k8spacket

[root@k8s-master-1 k8spacket]# helm install k8spacket --namespace k8spacket . --create-namespace
NAME: k8spacket
LAST DEPLOYED: Thu Oct 27 21:47:38 2022
NAMESPACE: k8spacket
STATUS: deployed
REVISION: 1
TEST SUITE: None
NOTES:
1. Get the application URL by running these commands:
  export NODE_PORT=$(kubectl get --namespace k8spacket -o jsonpath="{.spec.ports[0].nodePort}" services k8spacket)
  export NODE_IP=$(kubectl get nodes --namespace k8spacket -o jsonpath="{.items[0].status.addresses[0].address}")
  echo http://$NODE_IP:$NODE_PORT
[root@k8s-master-1 k8spacket]#

查看验证

[root@k8s-master-1 ~]# kubectl  get pod -n k8spacket  -o wide
NAME              READY   STATUS    RESTARTS   AGE     IP             NODE           NOMINATED NODE   READINESS GATES
k8spacket-8kxnx   1/1     Running   0          4m27s   192.168.1.66   k8s-node-3     <none>           <none>
k8spacket-cqpks   1/1     Running   0          4m27s   192.168.1.70   k8s-node-6     <none>           <none>
k8spacket-h72fc   1/1     Running   0          4m27s   192.168.1.67   k8s-node-4     <none>           <none>
k8spacket-jkxg9   1/1     Running   0          4m27s   192.168.1.75   k8s-node-7     <none>           <none>
k8spacket-kgpql   1/1     Running   0          4m27s   192.168.1.62   k8s-master-2   <none>           <none>
k8spacket-lf9br   1/1     Running   0          4m27s   192.168.1.61   k8s-master-1   <none>           <none>
k8spacket-mcbv5   1/1     Running   0          4m27s   192.168.1.68   k8s-node-5     <none>           <none>
k8spacket-ndlzt   1/1     Running   0          4m27s   192.168.1.64   k8s-node-1     <none>           <none>
k8spacket-vfg2x   1/1     Running   0          4m27s   192.168.1.63   k8s-master-3   <none>           <none>
k8spacket-vvwtr   1/1     Running   0          4m27s   192.168.1.65   k8s-node-2     <none>           <none>
[root@k8s-master-1 ~]#

[root@k8s-master-1 ~]# kubectl  get svc -n k8spacket  -o wide
NAME        TYPE        CLUSTER-IP     EXTERNAL-IP   PORT(S)    AGE     SELECTOR
k8spacket   ClusterIP   10.110.30.53   <none>        8080/TCP   4m31s   app.kubernetes.io/instance=k8spacket,app.kubernetes.io/name=k8spacket
[root@k8s-master-1 ~]#


访问验证
[root@k8s-master-1 ~]# curl 10.110.30.53:8080/metrics

安装 dashboards 配置

[root@k8s-master-1 ~]# cd /tmp/
[root@k8s-master-1 tmp]#
[root@k8s-master-1 tmp]# wget https://github.com/k8spacket/k8spacket/archive/refs/heads/master.zip
[root@k8s-master-1 tmp]# unzip master.zip
[root@k8s-master-1 tmp]#
[root@k8s-master-1 tmp]# cd k8spacket-master
[root@k8s-master-1 k8spacket-master]#
[root@k8s-master-1 k8spacket-master]# kubectl apply -f ./dashboards/
configmap/k8spacket-logs-dashboard created
configmap/k8spacket-metrics-dashboard created
configmap/k8spacket-node-graph-dashboard created
[root@k8s-master-1 k8spacket-master]#

安装 Grafana

[root@k8s-master-1 tmp]# helm repo add grafana https://grafana.github.io/helm-charts
"grafana" has been added to your repositories
[root@k8s-master-1 tmp]# helm fetch grafana/grafana
[root@k8s-master-1 tmp]#
[root@k8s-master-1 tmp]# tar -zxf grafana-6.43.1.tgz

修改Grafana配置内容

[root@k8s-master-1 tmp]# cd grafana/
[root@k8s-master-1 grafana]#
[root@k8s-master-1 grafana]# vim values.yaml

修改以下配置内容

persistence:
  type: pvc
  enabled: true

env:
  GF_INSTALL_PLUGINS: hamedkarbasi93-nodegraphapi-datasource

dashboardProviders:
  dashboardproviders.yaml:
    apiVersion: 1
    providers:
    - name: 'default'
      orgId: 1
      folder: ''
      type: file
      disableDeletion: false
      editable: true
      options:
        path: /var/lib/grafana/dashboards/default

dashboardsConfigMaps:
  default: k8spacket-node-graph-dashboard

datasources:
  nodegraphapi-plugin-datasource.yaml:
      apiVersion: 1
      datasources:
      - name: "Node Graph API"
        jsonData:
          url: "http://k8spacket.k8spacket.svc.cluster.local:8080"
        access: "proxy"
        basicAuth: false
        isDefault: false
        readOnly: false
        type: "hamedkarbasi93-nodegraphapi-datasource"
        typeLogoUrl: "public/plugins/hamedkarbasi93-nodegraphapi-datasource/img/logo.svg"
        typeName: "node-graph-plugin"
        orgId: 1
        version: 1

安装Grafana

[root@k8s-master-1 grafana]# helm install grafana -f values.yaml  ./
NAME: grafana
LAST DEPLOYED: Thu Oct 27 22:11:27 2022
NAMESPACE: default
STATUS: deployed
REVISION: 1
NOTES:
1. Get your 'admin' user password by running:

   kubectl get secret --namespace default grafana -o jsonpath="{.data.admin-password}" | base64 --decode ; echo

2. The Grafana server can be accessed via port 80 on the following DNS name from within your cluster:

   grafana.default.svc.cluster.local

   Get the Grafana URL to visit by running these commands in the same shell:

     export POD_NAME=$(kubectl get pods --namespace default -l "app.kubernetes.io/name=grafana,app.kubernetes.io/instance=grafana" -o jsonpath="{.items[0].metadata.name}")
     kubectl --namespace default port-forward $POD_NAME 3000

3. Login with the password from step 1 and the username: admin
[root@k8s-master-1 grafana]#

修改为NodePort

[root@k8s-master-1 grafana]# kubectl  get svc
NAME                   TYPE        CLUSTER-IP       EXTERNAL-IP   PORT(S)          AGE
echo-a                 ClusterIP   10.108.160.226   <none>        8080/TCP         6d9h
echo-b                 NodePort    10.108.200.169   <none>        8080:31414/TCP   6d9h
echo-b-headless        ClusterIP   None             <none>        8080/TCP         6d9h
echo-b-host-headless   ClusterIP   None             <none>        <none>           6d9h
grafana                ClusterIP   10.101.109.183   <none>        80/TCP           4m
kubernetes             ClusterIP   10.96.0.1        <none>        443/TCP          6d9h
[root@k8s-master-1 grafana]#

[root@k8s-master-1 grafana]# kubectl  edit svc grafana
service/grafana edited
[root@k8s-master-1 grafana]#
[root@k8s-master-1 grafana]# kubectl  get svc
NAME                   TYPE        CLUSTER-IP       EXTERNAL-IP   PORT(S)          AGE
echo-a                 ClusterIP   10.108.160.226   <none>        8080/TCP         6d9h
echo-b                 NodePort    10.108.200.169   <none>        8080:31414/TCP   6d9h
echo-b-headless        ClusterIP   None             <none>        8080/TCP         6d9h
echo-b-host-headless   ClusterIP   None             <none>        <none>           6d9h
grafana                NodePort    10.101.109.183   <none>        80:30973/TCP     4m37s
kubernetes             ClusterIP   10.96.0.1        <none>        443/TCP          6d9h
[root@k8s-master-1 grafana]#

查看Grafana密码

[root@k8s-master-1 grafana]# kubectl get secret --namespace default grafana -o jsonpath="{.data.admin-password}" | base64 --decode ; echo
9O1Hd9LOqJ6LKUjZTlEWAGeXRitr0CZd4p6fr00J
[root@k8s-master-1 grafana]#

访问地址

访问
http://192.168.1.61:30973/

添加 Node Graph API 插件
http://192.168.1.61:30973/plugins

查看 Node Graph API 数据收集源
http://192.168.1.61:30973/datasources

关于
https://www.oiox.cn/

https://www.oiox.cn/index.php/start-page.html

CSDN、GitHub、51CTO、知乎、开源中国、思否、掘金、简书、华为云、阿里云、腾讯云、哔哩哔哩、今日头条、新浪微博、个人博客

全网可搜《小陈运维》

文章主要发布于微信公众号

kubernetes 的TCP 数据包可视化

kubernetes 的TCP 数据包可视化

介绍

添加 k8spacket 的helm源

查看 pod 信息

查看报错为 tunl0 问题

修改配置

重新安装 k8spacket

查看验证

安装 dashboards 配置

安装 Grafana

修改Grafana配置内容

安装Grafana

修改为NodePort

查看Grafana密码

访问地址

热门文章

最新文章

相关课程

相关电子书

相关实验场景

推荐镜像

热门

活动广场

任务中心

开发者评测

高校计划

乘风者计划

训练营

阿里云MVP

话题

直播

下载

镜像站

技术资料

插件

kubernetes 的TCP 数据包可视化

kubernetes 的TCP 数据包可视化

介绍

添加 k8spacket 的helm源

查看 pod 信息

查看报错为 tunl0 问题

修改配置

重新安装 k8spacket

查看验证

安装 dashboards 配置

安装 Grafana

修改Grafana配置内容

安装Grafana

修改为NodePort

查看Grafana密码

访问地址

热门文章

最新文章

相关课程

相关电子书

相关实验场景

推荐镜像
