3.CCFadeOutTRTiles，部落格效果，跳动的方块特效，3D瓷砖晃动特效，破碎的3D瓷砖特效，瓷砖洗牌特效，分多行消失特效，分多列消失特效

1 TiledGrid3D

//TiledGrid3D

//CCFadeOutTRTiles * action = CCFadeOutTRTiles::create(2,

CCSize(20,20));

//CCFadeOutBLTiles * action = CCFadeOutBLTiles::create(2,

CCSize(20,20));

//CCJumpTiles3D * action = CCJumpTiles3D::create(2,

CCSize(4,4),20,20);

//CCShakyTiles3D * action = CCShakyTiles3D::create(2, CCSize(20,

20), 30, false);

//CCShatteredTiles3D * action = CCShatteredTiles3D::create(2,

CCSize(20,20),20,false);

//CCShuffleTiles * action = CCShuffleTiles::create(2,

CCSize(20,20),2);

//CCSplitCols * action = CCSplitCols::create(2, 20);

//CCSplitRows * action = CCSplitRows::create(2, 20);

//CCTurnOffTiles * action = CCTurnOffTiles::create(2,

CCSize(20,20));

CCWavesTiles3D * action = CCWavesTiles3D::create(2,

CCSize(20,20),20,30);

spr->runAction(action);



部落网格效果，从左下角到右下角

CCActionInterval* fadeOutTRTiles = CCFadeOutTRTiles::create(5, CCSize(50, 50));

sp->runAction(fadeOutTRTiles);

//参数1：特效持续的时间

//参数2：网格大小

#include "T18Grid3D.h"

#include "AppMacros.h"



CCScene *T18Grid3D::scene()

{

    CCScene * scene = CCScene::create();

    T18Grid3D * layer = T18Grid3D::create();

    scene->addChild(layer);

    return scene;

}



bool T18Grid3D::init()

{

    TBack::init();



    //Grid3D

    CCSprite * spr = CCSprite::create("HelloWorld.png");

    spr->setPosition(ccp(winSize.width / 2, winSize.height / 2));

    addChild(spr);



    CCFadeOutTRTiles * action = CCFadeOutTRTiles::create(

        20,

        CCSize(20, 20));



    spr->runAction(action);



    return true;

}

运行结果：

跳动的方块特效

CCActionInterval* jumpTitles = CCJumpTitles3D::create(5,CCSize(20,20),5,20);

sp->runAction(jumpTiles);

作用：跳动的方格特效

参数1：特效持续的时间

参数2：网格的大小

参数3：跳动的次数

参数4：跳动的振幅

#include "T18Grid3D.h"

#include "AppMacros.h"



CCScene *T18Grid3D::scene()

{

    CCScene * scene = CCScene::create();

    T18Grid3D * layer = T18Grid3D::create();

    scene->addChild(layer);

    return scene;

}



bool T18Grid3D::init()

{

    TBack::init();



    //Grid3D

    CCSprite * spr = CCSprite::create("HelloWorld.png");

    spr->setPosition(ccp(winSize.width / 2, winSize.height / 2));

    addChild(spr);



    CCActionInterval* jumpTiles = CCJumpTiles3D::create(

        5,              //特效持续的时间

        CCSize(20,20),  //网格的大小

        5,              //跳动的次数

        20);            //跳动的振幅



    spr->runAction(jumpTiles);



    return true;

}

3D 瓷砖晃动特效

CCActionInterval* shakyTiles3D = CCShakyTiles3D::create(5, CCSize(10, 10), 5, false);

sp->runAction(shakyTiles3D);

作用：创建一个3d瓷砖晃动的特效

参数1：特效持续的时间

参数2：网格大小

参数3：晃动的范围

参数5：是否有z轴晃动

#include "T18Grid3D.h"

#include "AppMacros.h"



CCScene *T18Grid3D::scene()

{

    CCScene * scene = CCScene::create();

    T18Grid3D * layer = T18Grid3D::create();

    scene->addChild(layer);

    return scene;

}



bool T18Grid3D::init()

{

    TBack::init();



    //Grid3D

    CCSprite * spr = CCSprite::create("HelloWorld.png");

    spr->setPosition(ccp(winSize.width / 2, winSize.height / 2));

    addChild(spr);



    CCActionInterval* shakyTiles3D = CCShakyTiles3D::create(

        5,                //特效持续的时间

        CCSize(10, 10),   //网格大小

        5,                //晃动的范围

        false);           //是否有z轴晃动



    spr->runAction(shakyTiles3D);



    return true;

}

运行结果：

破碎的3D瓷砖特效

CCActionInterval* shatteredTiles = CCShatteredTiles3D::create(15, CCSize(10, 10), 50, true);

sp->runAction(shatteredTiles);

作用：破碎的3D瓷砖特效

参数1：特效持续的时间

参数2：网格大小

参数3：范围

参数4：是否开启z轴

#include "T18Grid3D.h"

#include "AppMacros.h"



CCScene *T18Grid3D::scene()

{

    CCScene * scene = CCScene::create();

    T18Grid3D * layer = T18Grid3D::create();

    scene->addChild(layer);

    return scene;

}



bool T18Grid3D::init()

{

    TBack::init();



    //Grid3D

    CCSprite * spr = CCSprite::create("HelloWorld.png");

    spr->setPosition(ccp(winSize.width / 2, winSize.height / 2));

    addChild(spr);



    CCActionInterval* shatteredTiles = CCShatteredTiles3D::create(

        15,                  //特效持续的时间

        CCSize(10,10),       //网格大小

        50,                  //范围

        true);               //是否开启z轴



    spr->runAction(shatteredTiles);



    return true;

}

运行结果（特点是破碎的状态）：

瓷砖洗牌特效：

CCActionInterval* shuffle = CCShuffleTiles::create(5, CCSize(50, 50), 50);

作用：瓷砖的洗牌特效

参数1：特效持续的时间

参数2：网格大小

参数3：随机数

#include "T18Grid3D.h"

#include "AppMacros.h"



CCScene *T18Grid3D::scene()

{

    CCScene * scene = CCScene::create();

    T18Grid3D * layer = T18Grid3D::create();

    scene->addChild(layer);

    return scene;

}



bool T18Grid3D::init()

{

    TBack::init();



    //Grid3D

    CCSprite * spr = CCSprite::create("HelloWorld.png");

    spr->setPosition(ccp(winSize.width / 2, winSize.height / 2));

    addChild(spr);



    CCActionInterval * shuffle = CCShuffleTiles::create(

        5,                //特效的持续时间

        CCSize(50,50),    //网格的大小

        50);              //随机数



    spr->runAction(shuffle);



    return true;

}

运行效果：

分多行消失特效

CCActionInterval* splitCols = CCSplitCols::create(5,50);

sp->runAction(splitCols);

作用：分多列消失特效

参数1：特效持续的时间

参数2：列数

#include "T18Grid3D.h"

#include "AppMacros.h"



CCScene *T18Grid3D::scene()

{

    CCScene * scene = CCScene::create();

    T18Grid3D * layer = T18Grid3D::create();

    scene->addChild(layer);

    return scene;

}



bool T18Grid3D::init()

{

    TBack::init();



    //Grid3D

    CCSprite * spr = CCSprite::create("HelloWorld.png");

    spr->setPosition(ccp(winSize.width / 2, winSize.height / 2));

    addChild(spr);



    CCActionInterval * splitCols = CCSplitCols::create(5,20);



    spr->runAction(splitCols);



    return true;

}

运行效果：

分多列消失特效

CCActionInterval* splitRows = CCSplitRows::create(5, 50);

sp->runAction(splitRows);



作用：分多行消失特效

参数1：特效持续的时间

参数2：行数

#include "T18Grid3D.h"

#include "AppMacros.h"



CCScene *T18Grid3D::scene()

{

    CCScene * scene = CCScene::create();

    T18Grid3D * layer = T18Grid3D::create();

    scene->addChild(layer);

    return scene;

}



bool T18Grid3D::init()

{

    TBack::init();



    //Grid3D

    CCSprite * spr = CCSprite::create("HelloWorld.png");

    spr->setPosition(ccp(winSize.width / 2, winSize.height / 2));

    addChild(spr);



    CCActionInterval * splitRows = CCSplitRows::create(5, 50);



    spr->runAction(splitRows);



    return true;

}

运行结果：

方块消失特效

CCActionInterval* turnOffFiels = CCTurnOffTiles::create(4, CCSize(50, 50));

sp->runAction(turnOffFiles);

作用：方块消失特效

参数1：特效持续的时间

参数2：网络大小

#include "T18Grid3D.h"

#include "AppMacros.h"



CCScene *T18Grid3D::scene()

{

    CCScene * scene = CCScene::create();

    T18Grid3D * layer = T18Grid3D::create();

    scene->addChild(layer);

    return scene;

}



bool T18Grid3D::init()

{

    TBack::init();



    //Grid3D

    CCSprite * spr = CCSprite::create("HelloWorld.png");

    spr->setPosition(ccp(winSize.width / 2, winSize.height / 2));

    addChild(spr);



    CCActionInterval * turnOffFiles = CCTurnOffTiles::create(

        4,                 //特效持续的时间

        CCSize(50,50));    //网格大小



    spr->runAction(turnOffFiles);



    return true;

}

运行结果（渐渐消失）：

3D瓷砖波动特效

CCActionInterval * turnOffFiles = CCTurnOffTiles::create(

4,

CCSize(10,10),

10,

20);

作用：创建一个3D瓷砖波动特效

参数1：特效持续时间

参数2：网格大小

参数3：波动的速率

参数4：振幅

#include "T18Grid3D.h"

#include "AppMacros.h"



CCScene *T18Grid3D::scene()

{

    CCScene * scene = CCScene::create();

    T18Grid3D * layer = T18Grid3D::create();

    scene->addChild(layer);

    return scene;

}



bool T18Grid3D::init()

{

    TBack::init();



    //Grid3D

    CCSprite * spr = CCSprite::create("HelloWorld.png");

    spr->setPosition(ccp(winSize.width / 2, winSize.height / 2));

    addChild(spr);



    //3D瓷砖波动特效

    CCActionInterval* wavesTiles3D = CCWavesTiles3D::create(

        5,               //特效持续时间

        CCSize(10, 10),  //网格大小

        10,              //波动的速率

        20);             //振幅



    spr->runAction(wavesTiles3D);



    return true;

}

运行结果：
