类的结构分析

int main(int argc, const char * argv[]) {
    @autoreleasepool {
        //ISA_MASK  0x00007ffffffffff8ULL
        CJLPerson *person = [CJLPerson alloc];
        CJLTeacher *teacher = [CJLTeacher alloc];
        NSLog(@"Hello, World! %@ - %@",person,teacher);
    }
    return 0;
}

struct objc_class : objc_object {
    // Class ISA;   //8字节
    Class superclass;   //Class是由objc_object定义的, 是一个指针, 8字节
    cache_t cache;             // formerly cache pointer and vtable  //结构体要具体分析里面的属性, 分析出来也是8字节
    class_data_bits_t bits;    // class_rw_t * plus custom rr/alloc flags
    class_rw_t *data() const {
        return bits.data();
    }
    void setData(class_rw_t *newData) {
        bits.setData(newData);
    }
    void setInfo(uint32_t set) {
        ASSERT(isFuture()  ||  isRealized());
        data()->setFlags(set);
    }
    void clearInfo(uint32_t clear) {
        ASSERT(isFuture()  ||  isRealized());
        data()->clearFlags(clear);
    }
    // set and clear must not overlap
    void changeInfo(uint32_t set, uint32_t clear) {
        ASSERT(isFuture()  ||  isRealized());
        ASSERT((set & clear) == 0);
        data()->changeFlags(set, clear);
    }

/// Represents an instance of a class.
struct objc_object {
    Class _Nonnull isa  OBJC_ISA_AVAILABILITY;
};

//数组指针
    int c[4] = {1, 2, 3, 4};
    int *d = c;
    NSLog(@"%p -- %p - %p", &c, &c[0], &c[1]);
    NSLog(@"%p -- %p - %p", d, d+1, d+2);

struct cache_t {
#if CACHE_MASK_STORAGE == CACHE_MASK_STORAGE_OUTLINED
    explicit_atomic<struct bucket_t *> _buckets;  //*指针, 占8字节
    explicit_atomic<mask_t> _mask;  //mask_t 是unsigned int 的别名, 占4字节
#elif CACHE_MASK_STORAGE == CACHE_MASK_STORAGE_HIGH_16
    explicit_atomic<uintptr_t> _maskAndBuckets;  //uintptr_t 是一个指针, 8字节
    mask_t _mask_unused;  //mask_t 是unsigned int 的别名, 占4字节
    // How much the mask is shifted by.
    static constexpr uintptr_t maskShift = 48;   //static 静态类型不存储在结构体中, 所以不算是结构体的内存
    // Additional bits after the mask which must be zero. msgSend
    // takes advantage of these additional bits to construct the value
    // `mask << 4` from `_maskAndBuckets` in a single instruction.
    static constexpr uintptr_t maskZeroBits = 4;
    // The largest mask value we can store.
    static constexpr uintptr_t maxMask = ((uintptr_t)1 << (64 - maskShift)) - 1;
    // The mask applied to `_maskAndBuckets` to retrieve the buckets pointer.
    static constexpr uintptr_t bucketsMask = ((uintptr_t)1 << (maskShift - maskZeroBits)) - 1;
    // Ensure we have enough bits for the buckets pointer.
    static_assert(bucketsMask >= MACH_VM_MAX_ADDRESS, "Bucket field doesn't have enough bits for arbitrary pointers.");
#elif CACHE_MASK_STORAGE == CACHE_MASK_STORAGE_LOW_4
    // _maskAndBuckets stores the mask shift in the low 4 bits, and
    // the buckets pointer in the remainder of the value. The mask
    // shift is the value where (0xffff >> shift) produces the correct
    // mask. This is equal to 16 - log2(cache_size).
    explicit_atomic<uintptr_t> _maskAndBuckets;
    mask_t _mask_unused;
    static constexpr uintptr_t maskBits = 4;
    static constexpr uintptr_t maskMask = (1 << maskBits) - 1;
    static constexpr uintptr_t bucketsMask = ~maskMask;
#else
#error Unknown cache mask storage type.
#endif
#if __LP64__
    uint16_t _flags;  //uint16_t 是unsigned short的别名 占2个字节
#endif
    uint16_t _occupied;  //uint16_t 是unsigned short的别名 占2个字节
