简介
上一篇文章《Eureka 源码分析之 Eureka Client》 通过源码知道 ，eureka Client 是通过 http rest来 与 eureka server 交互，实现 注册服务，续约服务，服务下线 等。本篇探究下eureka server。
源码分析
从 @EnableEurekaServer 注解为入口分析，通过源码可以看出他是一个标记注解：
/**
* Annotation to activate Eureka Server related configuration {@link
*/
@Target(ElementType.TYPE)
@Retention(RetentionPolicy.RUNTIME)
@Documented
@Import(EurekaServerMarkerConfiguration.class)
public @interface EnableEurekaServer {
}从注释可以知道，用来激活 eureka server 的 配置类 EurekaServerAutoConfiguration 中相关配置，EurekaServerAutoConfiguration 的关键代码如下：
@Configuration
@Import(EurekaServerInitializerConfiguration.class)
@ConditionalOnBean(EurekaServerMarkerConfiguration.Marker.class)
@EnableConfigurationProperties({ EurekaDashboardProperties.class,
InstanceRegistryProperties.class })
@PropertySource("classpath:/eureka/server.properties")
public class EurekaServerAutoConfiguration extends WebMvcConfigurerAdapter {
/**
* List of packages containing Jersey resources required by the Eureka server
*/
private static final String[] EUREKA_PACKAGES = new String[] { "com.netflix.discovery",
"com.netflix.eureka" };
@Autowired
private ApplicationInfoManager applicationInfoManager;
@Autowired
private EurekaServerConfig eurekaServerConfig;
@Autowired
private EurekaClientConfig eurekaClientConfig;
@Autowired
private EurekaClient eurekaClient;
@Autowired
private InstanceRegistryProperties instanceRegistryProperties;
public static final CloudJacksonJson JACKSON_JSON = new CloudJacksonJson();
@Bean
public HasFeatures eurekaServerFeature() {
return HasFeatures.namedFeature("Eureka Server",
EurekaServerAutoConfiguration.class);
}
@Configuration
protected static class EurekaServerConfigBeanConfiguration {
// 创建并加载EurekaServerConfig的实现类，主要是Eureka-server的配置信息
@Bean
@ConditionalOnMissingBean
public EurekaServerConfig eurekaServerConfig(EurekaClientConfig clientConfig) {
EurekaServerConfigBean server = new EurekaServerConfigBean();
if (clientConfig.shouldRegisterWithEureka()) {
// Set a sensible default if we are supposed to replicate
server.setRegistrySyncRetries(5);
}
return server;
}
}
//加载EurekaController，SpringCloud 提供了一些额外的接口，用来获取eurekaServer的信息
@Bean
@ConditionalOnProperty(prefix = "eureka.dashboard", name = "enabled", matchIfMissing = true)
public EurekaController eurekaController() {
return new EurekaController(this.applicationInfoManager);
}
//省略 ...
// 接收客户端的注册等请求就是通过InstanceRegistry来处理的，是真正处理业务的类，接下来会详细分析
@Bean
public PeerAwareInstanceRegistry peerAwareInstanceRegistry(
ServerCodecs serverCodecs) {
this.eurekaClient.getApplications(); // force initialization
return new InstanceRegistry(this.eurekaServerConfig, this.eurekaClientConfig,
serverCodecs, this.eurekaClient,
this.instanceRegistryProperties.getExpectedNumberOfRenewsPerMin(),
this.instanceRegistryProperties.getDefaultOpenForTrafficCount());
}
//配置服务节点信息，这里的作用主要是为了配置Eureka的peer节点，也就是说当有收到有节点注册上来的时候，需要通知给哪些节点
@Bean
@ConditionalOnMissingBean
public PeerEurekaNodes peerEurekaNodes(PeerAwareInstanceRegistry registry,
ServerCodecs serverCodecs) {
return new RefreshablePeerEurekaNodes(registry, this.eurekaServerConfig,
this.eurekaClientConfig, serverCodecs, this.applicationInfoManager);
}
//省略 ...
//EurekaServer的上下文
@Bean
public EurekaServerContext eurekaServerContext(ServerCodecs serverCodecs,
PeerAwareInstanceRegistry registry, PeerEurekaNodes peerEurekaNodes) {
return new DefaultEurekaServerContext(this.eurekaServerConfig, serverCodecs,
registry, peerEurekaNodes, this.applicationInfoManager);
}
// 初始化Eureka-server，会同步其他注册中心的数据到当前注册中心
@Bean
public EurekaServerBootstrap eurekaServerBootstrap(PeerAwareInstanceRegistry registry,
EurekaServerContext serverContext) {
return new EurekaServerBootstrap(this.applicationInfoManager,
this.eurekaClientConfig, this.eurekaServerConfig, registry,
serverContext);
}
// 配置拦截器，ServletContainer里面实现了jersey框架，通过他来实现eurekaServer对外的restFull接口
@Bean
public FilterRegistrationBean jerseyFilterRegistration(
javax.ws.rs.core.Application eurekaJerseyApp) {
FilterRegistrationBean bean = new FilterRegistrationBean();
bean.setFilter(new ServletContainer(eurekaJerseyApp));
bean.setOrder(Ordered.LOWEST_PRECEDENCE);
bean.setUrlPatterns(
Collections.singletonList(EurekaConstants.DEFAULT_PREFIX + "/*"));
return bean;
}
//省略 ...
}从EurekaServerAutoConfiguration 类上的注解@Import(EurekaServerInitializerConfiguration.class) 可以到，实例化类EurekaServerAutoConfiguration之前，已经实例化了EurekaServerInitializerConfiguration类，代码如下：
@Configuration
@CommonsLog
public class EurekaServerInitializerConfiguration
implements ServletContextAware, SmartLifecycle, Ordered {
// 此处省略部分代码
@Override
public void start() {
// 启动一个线程
new Thread(new Runnable() {
@Override
public void run() {
try {
//初始化EurekaServer，同时启动Eureka Server ，后面着重讲这里
eurekaServerBootstrap.contextInitialized(EurekaServerInitializerConfiguration.this.servletContext);
log.info("Started Eureka Server");
// 发布EurekaServer的注册事件
publish(new EurekaRegistryAvailableEvent(getEurekaServerConfig()));
// 设置启动的状态为true
EurekaServerInitializerConfiguration.this.running = true;
// 发送Eureka Start 事件 ， 其他还有各种事件，我们可以监听这种时间，然后做一些特定的业务需求，后面会讲到。
publish(new EurekaServerStartedEvent(getEurekaServerConfig()));
}
catch (Exception ex) {
// Help!
log.error("Could not initialize Eureka servlet context", ex);
}
}
}).start();
}
// 此处省略部分代码
}这个start方法中开启了一个新的线程，然后进行一些Eureka Server的初始化工作，比如调用eurekaServerBootstrap的contextInitialized方法，EurekaServerBootstrap代码如下：
public class EurekaServerBootstrap {
// 此处省略部分代码
public void contextInitialized(ServletContext context) {
try {
// 初始化Eureka的环境变量
initEurekaEnvironment();
// 初始化Eureka的上下文
initEurekaServerContext();
context.setAttribute(EurekaServerContext.class.getName(), this.serverContext);
}
catch (Throwable e) {
log.error("Cannot bootstrap eureka server :", e);
throw new RuntimeException("Cannot bootstrap eureka server :", e);
}
}
protected void initEurekaEnvironment() throws Exception {
log.info("Setting the eureka configuration..");
String dataCenter = ConfigurationManager.getConfigInstance()
.getString(EUREKA_DATACENTER);
if (dataCenter == null) {
log.info(
"Eureka data center value eureka.datacenter is not set, defaulting to default");
ConfigurationManager.getConfigInstance()
.setProperty(ARCHAIUS_DEPLOYMENT_DATACENTER, DEFAULT);
}
else {
ConfigurationManager.getConfigInstance()
.setProperty(ARCHAIUS_DEPLOYMENT_DATACENTER, dataCenter);
}
String environment = ConfigurationManager.getConfigInstance()
.getString(EUREKA_ENVIRONMENT);
if (environment == null) {
ConfigurationManager.getConfigInstance()
.setProperty(ARCHAIUS_DEPLOYMENT_ENVIRONMENT, TEST);
log.info(
"Eureka environment value eureka.environment is not set, defaulting to test");
}
else {
ConfigurationManager.getConfigInstance()
.setProperty(ARCHAIUS_DEPLOYMENT_ENVIRONMENT, environment);
}
}
protected void initEurekaServerContext() throws Exception {
// For backward compatibility
JsonXStream.getInstance().registerConverter(new V1AwareInstanceInfoConverter(),
XStream.PRIORITY_VERY_HIGH);
XmlXStream.getInstance().registerConverter(new V1AwareInstanceInfoConverter(),
XStream.PRIORITY_VERY_HIGH);
if (isAws(this.applicationInfoManager.getInfo())) {
this.awsBinder = new AwsBinderDelegate(this.eurekaServerConfig,
this.eurekaClientConfig, this.registry, this.applicationInfoManager);
this.awsBinder.start();
}
//初始化eureka server上下文
EurekaServerContextHolder.initialize(this.serverContext);
log.info("Initialized server context");
// Copy registry from neighboring eureka node
// 从相邻的eureka节点复制注册表
int registryCount = this.registry.syncUp();
// 默认每30秒发送心跳，1分钟就是2次
// 修改eureka状态为up
// 同时，这里面会开启一个定时任务，用于清理 60秒没有心跳的客户端。自动下线
this.registry.openForTraffic(this.applicationInfoManager, registryCount);
// Register all monitoring statistics.
EurekaMonitors.registerAllStats();
}
public void contextDestroyed(ServletContext context) {
try {
log.info("Shutting down Eureka Server..");
context.removeAttribute(EurekaServerContext.class.getName());
destroyEurekaServerContext();
destroyEurekaEnvironment();
}
catch (Throwable e) {
log.error("Error shutting down eureka", e);
}
log.info("Eureka Service is now shutdown...");
}
}在初始化Eureka Server上下文环境后，就会继续执行openForTraffic方法，这个方法主要是设置了期望每分钟接收到的心跳次数，并将服务实例的状态设置为UP，最后又通过方法postInit来开启一个定时任务，用于每隔一段时间（默认60秒）将没有续约的服务实例（默认90秒没有续约）清理掉。openForTraffic的方法代码如下：
@Override
public void openForTraffic(ApplicationInfoManager applicationInfoManager, int count) {
// Renewals happen every 30 seconds and for a minute it should be a factor of 2.
// 计算每分钟最大续约数
this.expectedNumberOfRenewsPerMin = count * 2;
// 计算每分钟最小续约数
this.numberOfRenewsPerMinThreshold =
(int) (this.expectedNumberOfRenewsPerMin * serverConfig.getRenewalPercentThreshold());
logger.info("Got {} instances from neighboring DS node", count);
logger.info("Renew threshold is: {}", numberOfRenewsPerMinThreshold);
this.startupTime = System.currentTimeMillis();
if (count > 0) {
this.peerInstancesTransferEmptyOnStartup = false;
}
DataCenterInfo.Name selfName = applicationInfoManager.getInfo().getDataCenterInfo().getName();
boolean isAws = Name.Amazon == selfName;
if (isAws && serverConfig.shouldPrimeAwsReplicaConnections()) {
logger.info("Priming AWS connections for all replicas..");
primeAwsReplicas(applicationInfoManager);
}
logger.info("Changing status to UP");
// 修改服务实例的状态为UP
applicationInfoManager.setInstanceStatus(InstanceStatus.UP);
// 开启定时任务，每隔一段时间（默认60秒）将没有续约的服务实例（默认90秒没有续约）清理掉
super.postInit();
}postInit方法开启了一个新的定时任务，代码如下：
protected void postInit() {
renewsLastMin.start();
if (evictionTaskRef.get() != null) {
evictionTaskRef.get().cancel();
}
evictionTaskRef.set(new EvictionTask());
evictionTimer.schedule(evictionTaskRef.get(),
serverConfig.getEvictionIntervalTimerInMs(),
serverConfig.getEvictionIntervalTimerInMs());
}这里的时间间隔都来自于EurekaServerConfigBean类，可以在配置文件中以eureka.server开头的配置来进行设置。
