继上篇《Hadoop-2.6.0NodeManager Restart Recover实现分析（二）》。
4、NMLeveldbStateStoreService实现分析
在
1）、initStorage()
initStorage()方法中，完成了存储相关的初始化，如下：
@Override
protected void initStorage(Configuration conf)
throws IOException {
Path storeRoot = createStorageDir(conf);
Options options = new Options();
options.createIfMissing(false);
options.logger(new LeveldbLogger());
LOG.info("Using state database at " + storeRoot + " for recovery");
File dbfile = new File(storeRoot.toString());
try {
db = JniDBFactory.factory.open(dbfile, options);
} catch (NativeDB.DBException e) {
if (e.isNotFound() || e.getMessage().contains(" does not exist ")) {
LOG.info("Creating state database at " + dbfile);
isNewlyCreated = true;
options.createIfMissing(true);
try {
db = JniDBFactory.factory.open(dbfile, options);
// store version
storeVersion();
} catch (DBException dbErr) {
throw new IOException(dbErr.getMessage(), dbErr);
}
} else {
throw e;
}
}
checkVersion();
} 最主要的是通过JniDBFactory.factory.open(dbfile, options)打开了一个db实例。
2）startStorage()
为空。
3）closeStorage()
关闭db，如下：
@Override
protected void closeStorage() throws IOException {
if (db != null) {
db.close();
}
}
下面，以Applications为例，罗列下实现方式：
1）storeApplication()
存储Application，如下：
@Override
public void storeApplication(ApplicationId appId,
ContainerManagerApplicationProto p) throws IOException {
String key = APPLICATIONS_KEY_PREFIX + appId;
try {
db.put(bytes(key), p.toByteArray());
} catch (DBException e) {
throw new IOException(e);
}
}
key为ContainerManager/applications/再加appId，value为ContainerManagerApplicationProto，消息内容如下：
message ContainerManagerApplicationProto {
optional ApplicationIdProto id = 1;
optional string user = 2;
optional bytes credentials = 3;
repeated ApplicationACLMapProto acls = 4;
optional LogAggregationContextProto log_aggregation_context = 5;
}
2）storeFinishedApplication()
存储已完成Application，如下：
@Override
public void storeFinishedApplication(ApplicationId appId)
throws IOException {
String key = FINISHED_APPS_KEY_PREFIX + appId;
try {
db.put(bytes(key), new byte[0]);
} catch (DBException e) {
throw new IOException(e);
}
} 其中，key为ContainerManager/finishedApps/再加appId，value为空，即new byte[0]。
3） removeApplication()
删除Application，如下：
@Override
public void removeApplication(ApplicationId appId)
throws IOException {
try {
WriteBatch batch = db.createWriteBatch();
try {
String key = APPLICATIONS_KEY_PREFIX + appId;
batch.delete(bytes(key));
key = FINISHED_APPS_KEY_PREFIX + appId;
batch.delete(bytes(key));
db.write(batch);
} finally {
batch.close();
}
} catch (DBException e) {
throw new IOException(e);
}
} 根据各自的key分别删除storeApplication()和storeFinishedApplication()存储的Application信息，
4）loadApplicationsState()
加载所有的Application状态，以便进行recovery。如下：
加载所有的Application状态，以便进行recovery。如下：
@Override
public RecoveredApplicationsState loadApplicationsState()
throws IOException {
RecoveredApplicationsState state = new RecoveredApplicationsState();
state.applications = new ArrayList<ContainerManagerApplicationProto>();
String keyPrefix = APPLICATIONS_KEY_PREFIX;
LeveldbIterator iter = null;
try {
iter = new LeveldbIterator(db);
iter.seek(bytes(keyPrefix));
while (iter.hasNext()) {
Entry<byte[], byte[]> entry = iter.next();
String key = asString(entry.getKey());
if (!key.startsWith(keyPrefix)) {
break;
}
state.applications.add(
ContainerManagerApplicationProto.parseFrom(entry.getValue()));
}
state.finishedApplications = new ArrayList<ApplicationId>();
keyPrefix = FINISHED_APPS_KEY_PREFIX;
iter.seek(bytes(keyPrefix));
while (iter.hasNext()) {
Entry<byte[], byte[]> entry = iter.next();
String key = asString(entry.getKey());
if (!key.startsWith(keyPrefix)) {
break;
}
ApplicationId appId =
ConverterUtils.toApplicationId(key.substring(keyPrefix.length()));
state.finishedApplications.add(appId);
}
} catch (DBException e) {
throw new IOException(e);
} finally {
if (iter != null) {
iter.close();
}
}
return state;
}
通过LeveldbIterator和key的前缀ContainerManager/applications/进行load。
后续会分析哪些地方调用了上述方法，未完待续！
