并发设计模式实战系列(13)：双重检查锁定（Double-Checked Locking）

┌───────────────────────┐        ┌───────────────────────┐
│   第一次检查 (非同步)   │──No───>│       直接返回         │
│   (instance == null)  │        └───────────────────────┘
└──────────┬────────────┘
           │Yes
           v
┌───────────────────────┐        ┌───────────────────────┐
│      同步代码块        │──No───>│    创建新实例         │
│   (synchronized)      │        │ (instance = new T())  │
└──────────┬────────────┘        └──────────┬────────────┘
           │Yes                              │
           v                                v
┌───────────────────────┐        ┌───────────────────────┐
│   第二次检查          │        │       返回实例         │
│   (instance == null)  │        └───────────────────────┘
└───────────────────────┘

public class DoubleCheckedLocking {
    // 关键：volatile保证可见性和禁止指令重排序
    private volatile static DoubleCheckedLocking instance;
    private DoubleCheckedLocking() {
        // 防止反射创建实例
        if (instance != null) {
            throw new IllegalStateException("Already initialized");
        }
    }
    public static DoubleCheckedLocking getInstance() {
        // 第一次检查（无锁）
        if (instance == null) {
            synchronized (DoubleCheckedLocking.class) {
                // 第二次检查（持有锁）
                if (instance == null) {
                    instance = new DoubleCheckedLocking();
                    // 对象初始化分为三步：
                    // 1. 分配内存空间
                    // 2. 初始化对象
                    // 3. 设置引用指向内存地址
                    // volatile防止步骤2和3重排序
                }
            }
        }
        return instance;
    }
    public static void main(String[] args) {
        // 测试多线程环境
        for (int i = 0; i < 10; i++) {
            new Thread(() -> {
                System.out.println(Thread.currentThread().getName()
                    + "获取实例：" + DoubleCheckedLocking.getInstance());
            }).start();
        }
    }
}

// 错误实现示例（没有volatile）
private static Singleton instance;  // 可能导致部分初始化对象被读取
// 正确实现必须包含：
// 1. volatile修饰
// 2. 双重null检查
// 3. synchronized同步块

// 替代volatile的更优方案
private static Object instance;
private static final VarHandle INSTANCE;
static {
    try {
        INSTANCE = MethodHandles.lookup().findVarHandle(
            DoubleCheckedLocking.class, "instance", Object.class);
    } catch (Exception e) {
        throw new Error(e);
    }
}
public static Object getInstance() {
    Object localRef = instance;
    if (localRef == null) {
        synchronized (DoubleCheckedLocking.class) {
            localRef = instance;
            if (localRef == null) {
                localRef = new Object();
                INSTANCE.setRelease(localRef); // 比volatile更轻量级的写屏障
            }
        }
    }
    return localRef;
}

private static volatile boolean initialized = false;
private DoubleCheckedLocking() {
    synchronized (DoubleCheckedLocking.class) {
        if (initialized) {
            throw new IllegalStateException("Already initialized");
        }
        initialized = true;
    }
}

// 统计锁竞争情况
long contentionCount = DoubleCheckedLocking.class
    .getClassLoader()
    .getObjectMonitorUsageCount();

// 反例1：缺少volatile
class BrokenDCL {
    private static Singleton instance;  // 缺少volatile

    public static Singleton getInstance() {
        if (instance == null) {          // 第一次检查
            synchronized (BrokenDCL.class) {
                if (instance == null) {   // 第二次检查
                    instance = new Singleton();  // 可能发生指令重排序
                }
            }
        }
        return instance;
    }
}
// 反例2：方法级同步
class SlowSingleton {
    private static Singleton instance;

    public synchronized static Singleton getInstance() {  // 每次调用都同步
        if (instance == null) {
            instance = new Singleton();
        }
        return instance;
    }
}

public class HolderPattern {
    private HolderPattern() {}

    private static class Holder {
        static final HolderPattern INSTANCE = new HolderPattern();
    }

    public static HolderPattern getInstance() {
        return Holder.INSTANCE;  // 利用类加载机制保证线程安全
    }
}

public enum EnumSingleton {
    INSTANCE;

    public void businessMethod() {
        System.out.println("Executing business logic");
    }
}

class Singleton {
private:
    static std::atomic<Singleton*> instance;
    static std::mutex mtx;

    Singleton() = default;

public:
    static Singleton* getInstance() {
        Singleton* tmp = instance.load(std::memory_order_acquire);
        if (tmp == nullptr) {
            std::lock_guard<std::mutex> lock(mtx);
            tmp = instance.load(std::memory_order_relaxed);
            if (tmp == nullptr) {
                tmp = new Singleton();
                instance.store(tmp, std::memory_order_release);
            }
        }
        return tmp;
    }
};

Benchmark                      Mode  Cnt   Score   Error  Units
DCL_vs_Alternatives.dcl        avgt   10   3.451 ± 0.123  ns/op
DCL_vs_Alternatives.holder     avgt   10   2.893 ± 0.098  ns/op
DCL_vs_Alternatives.enum       avgt   10   2.901 ± 0.105  ns/op
DCL_vs_Alternatives.synchronized avgt 10  15.672 ± 0.456  ns/op

// 模拟Spring的AnnotationAwareAspectJAutoProxyCreator
public abstract class AbstractSingletonProxyFactory {
    private volatile Object proxyInstance;

    protected Object getSingletonProxy() {
        Object proxy = this.proxyInstance;
        if (proxy == null) {
            synchronized (this) {
                proxy = this.proxyInstance;
                if (proxy == null) {
                    proxy = createProxy();
                    this.proxyInstance = proxy;
                }
            }
        }
        return proxy;
    }

    protected abstract Object createProxy();
}
