【APIM】启用APIM Analytics时遇见Request failed错误

简介: Data collection is required for detailed monitoring, custom dashboards, and more. A Log Analytics workspace is also required for the data storage. You can change the workspace destination at any time in Diagnostic settings. How do I use Log Analytics?

问题描述

在APIM页面,查看Analytics的时候显示没有启用数据收集,无法分析。

Collect data from this resource for analytics

Data collection is required for detailed monitoring, custom dashboards, and more. A Log Analytics workspace is also required for the data storage. You can change the workspace destination at any time in Diagnostic settings. How do I use Log Analytics?

但是,根据页面提示,启用时发出的请求失败。

错误信息

{
"error": {
"code": "LinkedInvalidPropertyId",
"message": "Property id '' at path 'properties.workspaceId' is invalid.
Expect fully qualified resource Id that start with
'/subscriptions/{subscriptionId}'
or
'/providers/{resourceProviderNamespace}/'."
}
}

问题解答

因为这个错误是Azure门户上错误,无法被用户操作,所以从Analytics页面中,无法实现配置Log A Workspce的问题。但是可以在另一个地方【 Diagnostic settings (诊断设置)】中完成数据收集并且用于Analytics。



第一步:进入 Diagnostic settings ,点击添加 Diagnostic Setting

第二步:选择全部的 Logs 和 Metrics,并把信息保存到目标Log A Workspace中

第三步:自定义一个名称(任意字符串即可),保存后。回到Analytics页面。成功!



配置完成后,Analytics页面效果:






当在复杂的环境中面临问题,格物之道需:浊而静之徐清,安以动之徐生。 云中,恰是如此!
