编译原理 实验三 LL(1)分析法(LL1分析表的自动生成) 完整代码

简介: 编译原理 实验三 LL(1)分析法(LL1分析表的自动生成) 完整代码

思路分析

https://blog.csdn.net/qq_46640863/article/details/125689861

完整代码

#include<iostream>
#include<cstring>
#include<set>
#include<fstream>
#include<map>
#include<iomanip>
#include<vector>
#include<stack>
using namespace std;
string PATH = "F:/HOMEWORK/Compiler/Lab3/Project1/test.txt";//文法输入文件
char S;//开始符
set<char> VN, VT;//非终结符,终结符
map<char, vector<vector<string>>> MAP;//产生式表
map<char, set<char>> firstSet;//单个字符的FIRST集
map<string, set<char>> firstSetS;//符号串FIRST集
map<char, set<char>> followSet;//FOLLOW集合
map<char, vector<string>> expressionSet;
vector<vector<string>> table;//预测分析表本体
FILE* fin;
vector<string> filebuffer;//文件读取的缓冲区
vector<string> expression_withoutrecursion;//消左递归
vector<string> expression_withoutback;//消完左递归和回溯
vector<string> inputExpression;//最后增广完成,用于进行分析的文法
stack<char> analyzeStack;//分析栈
string action = "";
string strInput;//输入待分析的字符串
int index = 0;
void read() {
  //文法写在文件中
  ifstream fin(PATH);
  string str;
  if (!fin.is_open()){
    cout << "can not open this file" << endl;
    return;
  }
  while (fin >> str)
    filebuffer.push_back(str);
  for (string st : filebuffer)
    cout << st << endl;
}
//识别标识符与非标识符
void identifyVnVt() {
  S = filebuffer[0][0];
  for (string str : filebuffer){
    //产生式左部,必定是非终结符
    VN.insert(str[0]);
  }
  for (string str : filebuffer)
    for (int i = 1; i < str.size(); i++)
      //识别到了终结符
      if (str[i] != '-' && str[i] != '>' && str[i] != '|' && VN.count(str[i]) == 0)
        VT.insert(str[i]);
  cout << "文法开始符号:" << S << endl;
  cout << "文法非终结符:";
  for (auto ch : VN)
    cout << ch << " ";
  cout << endl;
  cout << "文法终结符:";
  for (auto ch : VT)
    cout << ch << " ";
}
void identifyVnVt2(){
  for (string str : inputExpression){
    //识别新插入的终结符
    VN.insert(str[0]);
  }
  for (string str : inputExpression){
    //识别新插入的非终结符
    //空字用e表示
    //文法结束符用#表示
    for (int i = 1; i < str.size(); i++){
      if (str[i] != '-' && str[i] != '>' && str[i] != '|' && VN.count(str[i]) == 0)
        VT.insert(str[i]);
    }
  }
  cout << "文法开始符号:" << S << endl;
  cout << "文法非终结符:";
  for (auto ch : VN)
    cout << ch << " ";
  cout << endl;
  cout << "文法终结符:";
  for (auto ch : VT)
    cout << ch << " ";
  cout << endl;
}
//消除左递归
void leftRecursion(){
  for (string str : filebuffer){
    if (str[0] == str[str.find('>') + 1]){
      char newch = 'A';
      for (newch = 'A'; newch <= 'Z'; newch++){
        if (VN.count(newch) == 0)
          break;
      }
      VN.insert(newch);
      string newstr = "";
      string alpha = str.substr(4, str.find('|') - 4);
      //A->betaA'
      newstr = newstr + str[0] + (string)"->" + str.substr(str.find('|') + 1) + newch;
      expression_withoutrecursion.push_back(newstr);
      newstr = "";
      //A'->alphaA'|e
      newstr = newstr + newch + "->" + alpha + newch + "|" + 'e';
      //e表示空字符episilon
      VT.insert('e');
      expression_withoutrecursion.push_back(newstr);
    }
    else
      expression_withoutrecursion.push_back(str);
  }
  cout << "\n消除左递归:\n";
  for (string str : expression_withoutrecursion)
    cout << str << endl;
}
//消除回溯
void leftTraceback(){
  for (string str : expression_withoutrecursion){
    //发现回溯
    if (str[3] == str[str.find("|") + 1]){
      char newch = 'A';
      for (newch = 'A'; newch <= 'Z'; newch++){
        if (VN.count(newch) == 0)
          break;
      }
      VN.insert(newch);
      string delta = "" + str[3];
      string newstr = "";
      //A->alphaA'
      newstr += str[0] + "->" + delta + newch;
      expression_withoutback.push_back(newstr);
      newstr = "";
      //A'->beta1|beta2
      string beta1 = str.substr(4, str.find('|') - 4);
      string beta2 = str.substr(str.find('|') + 1);
      newstr += newch + "->" + beta1 + '|' + beta2;
      expression_withoutback.push_back(newstr);
    }
    else
      expression_withoutback.push_back(str);
  }
  cout << "\n消除回溯:\n";
  for (string str : expression_withoutback)
    cout << str << endl;
}
//增广,删除竖线|
void deleteor(){
  for (string str : expression_withoutback){
    if (str.find('|') != string::npos){
      //将A->beta1|beta2拆成A->beta1和A->beta2
      string right1 = str.substr(3, str.find('|') - 3);
      string newstr1 = "";
      newstr1 = str[0] + (string)"->" + right1;
      inputExpression.push_back(newstr1);
      string right2 = str.substr(str.find('|') + 1);
      string newstr2 = "";
      newstr2 += str[0] + (string)"->" + right2;
      inputExpression.push_back(newstr2);
    }
    else
      inputExpression.push_back(str);
  }
  cout << "\n增广\n";
  for (string str : inputExpression)
    cout << str << endl;
}
//字符的求first集
void getFirst(char c){
  //已经求完了当前字符的first集
  if (firstSet.count(c))
    return;
  set<char> newset;
  //若c为终结符,则first为自己,结束
  if (VT.count(c)){
    newset.insert(c);
    firstSet[c] = newset;
    return;
  }
  for (string s : expressionSet[c]){
    //若存在X->e,将e加入
    if ('e' == c)
      newset.insert('e');
    else{
      for (char cur : s){
        if (!firstSet.count(cur))
          getFirst(cur);
        set<char> curFirst = firstSet[cur];
        for (auto curf : curFirst)
          newset.insert(curf);
        //将Y的first集合中的元素中不是e的加入
        if (!curFirst.count('e'))
          break;
        //如果加到了e,则循环回去,即X->Y1Y2..Yk时,Y1产生e,就需要加入Y2的first集合
      }
    }
  }
  firstSet[c] = newset;
}
//多个字符(字符串、短语)first集求法
void getFirst(string s){
  if (firstSetS.count(s))
    return;
  set<char> newset;
  int i = 0;
  while (i < s.length()){
    char cur = s[i];
    if (!firstSet.count(cur))
      getFirst(cur);
    //将当前字符的first集作为短语的first集
    set<char> rightSet = firstSet[cur];
    for (auto rs : rightSet)
      newset.insert(rs);
    //类似的,如果加到了e,则循环回去,即X->Y1Y2..Yk时,Y1产生e,就需要加入Y2的first集合
    if (rightSet.count('e'))
      i++;
    else
      break;
    //遍历完了当前语句后,将空字加入当前语句first集
    if (i == s.length())
      newset.insert('e');
  }
  firstSetS[s] = newset;
}
//某个字符的follow集合
void getFollow(char c){
  vector<string> list = expressionSet[c];
  set<char> leftFollowSet;
  if (followSet.count(c))
    leftFollowSet = followSet[c];
  //对文法开始符号,将#加入follow集合
  if (c == S)
    leftFollowSet.insert('#');
  for (char ch : VN) {
    for (string s : expressionSet[ch]) {
      for (int i = 0; i < s.length(); i++) {
        //若有A->aBb(a可为空),则将b加入B的follow集合
        if (c == s[i] && i + 1 < s.length() && VT.count(s[i + 1]))
          leftFollowSet.insert(s[i + 1]);
      }
    }
  }
  followSet[c] = leftFollowSet;
  for (string s : list){
    int i = s.length() - 1;
    //对每个产生式从右往左遍历
    while (i >= 0){
      char cur = s[i];
      //对于当前标识符B
      //对于当前标识符之后的字符,若是非终结符,则将这个非终结符的first集加入当前字符的follow集
      if (VN.count(cur)){
        string right = s.substr(i + 1);
        set<char> rightFirstSet;
        if (!followSet.count(cur))
          getFollow(cur);
        set<char> curFollowSet = followSet[cur];
        //若A->aB或A->aB\beta且\beta->e
        //则把follow(A)加到follow(B)
        if (right.length() == 0)
          for (auto lfs : leftFollowSet)
            curFollowSet.insert(lfs);
        else{
          //将若A->Bbeta,将B后的字符的first(除e)加入
          if (right.length() == 1){
            if (!firstSet.count(right[0]))
              getFirst(right[0]);
            rightFirstSet = firstSet[right[0]];
          }
          else{
            if (!firstSetS.count(right))
              getFirst(right);
            rightFirstSet = firstSetS[right];
          }
          for (char var : rightFirstSet)
            if (var != 'e')
              curFollowSet.insert(var);
          //若A->Bbeta且e属于first(beta),将follow(A)加入follow(B)
          if (rightFirstSet.count('e'))
            for (auto lfs : leftFollowSet)
              curFollowSet.insert(lfs);
        }
        followSet[cur] = curFollowSet;
      }
      i--;
    }
  }
}
//初始化
void init(){
  for (string e : inputExpression){
    string str = e.substr(e.find('>') + 1);
    char c = e[0];
    vector<string> list;
    if (expressionSet.count(c))
      list = expressionSet[c];
    list.push_back(str);
    expressionSet[c] = list;
  }
  //分理出每个产生时左部和右部
  for (auto node : expressionSet){
    cout << node.first << " ";
    for (auto nd : node.second)
      cout << nd << " ";
    cout << endl;
  }
  //求每个产生式first集合
  for (char c : VN)
    getFirst(c);
  cout << "\nFirst集合:\n";
  for (auto node : firstSet){
    cout << node.first << ":";
    for (auto nd : node.second)
      cout << nd << " ";
    cout << endl;
  }
  //求文法开始符的follow
  getFollow(S);
  //求每个非终结符的follow
  for (char c : VN)
    getFollow(c);
  cout << "\nFollow集合:\n";
  for (auto node : followSet){
    cout << node.first << ":";
    for (auto nd : node.second)
      cout << nd << " ";
    cout << endl;
  }
}
void insert(char X, char a, string s){
  if (a == 'e')
    a = '#';
  for (int i = 0; i < VN.size() + 1; i++){
    if (table[i][0][0] == X) {
      for (int j = 0; j < VT.size() + 1; j++){
        if (table[0][j][0] == a){
          table[i][j] = s;
          return;
        }
      }
    }
  }
}
//构造分析表
void createTable(){
  vector<char> VtArray;
  vector<char> VnArray;
  for (char node : VT)
    if (node != 'e')
      VtArray.push_back(node);
  VtArray.push_back('e');
  for (char node : VN)
    VnArray.push_back(node);
  table.resize(VnArray.size() + 1);
  for (int i = 0; i < VnArray.size() + 1; i++)
    table[i].resize(VtArray.size() + 1);
  for (int i = 0; i < VtArray.size(); i++){
    //e终结符视作#
    if (VtArray[i] == 'e')
      table[0][i + 1] = "#";
    else
      table[0][i + 1] = VtArray[i];
  }
  for (int i = 0; i < VnArray.size(); i++)
    table[i + 1][0] = VnArray[i];
  for (char A : VN){
    for (string s : expressionSet[A]){
      if (!firstSetS.count(s))
        getFirst(s);
      set<char> newset = firstSetS[s];
      for (char a : newset){
        string news = "";
        news += A;
        news += "->";
        news += s;
        insert(A, a, news);
      }
      //对于终结符a属于first(A),把A->a加入到M[A,a]中
      //若e属于first(A),则将Follow(A)的终结符加入
      if (newset.count('e')){
        set<char> setFollow = followSet[A];
        string news = "";
        news += A;
        news += "->e";
        if (setFollow.count('#'))
          insert(A, '#', news);
        for (char b : setFollow)
          insert(A, b, news);
      }
    }
  }
  for (int i = 0; i < VN.size() + 1; i++){
    for (int j = 0; j < VT.size() + 1; j++)
      cout << setw(10) << table[i][j];
    cout << endl;
  }
}
//输出分析表
void displayLL(){
  stack<char> stk = analyzeStack;
  string s = "";
  while (!stk.empty()){
    s += stk.top();
    stk.pop();
  }
  cout << setw(20) << s << setw(10) << strInput.substr(index) << setw(20) << action << endl;
}
//在分析表中找到非终结符X和a对应的表项
string find(char X, char a){
  for (int i = 0; i < VN.size() + 1; i++){
    if (table[i][0][0] == X){
      for (int j = 0; j < VT.size() + 1; j++){
        if (table[0][j][0] == a) {
          if (table[i][j] == "")
            return "";
          else
            return table[i][j].substr(3);
        }
      }
    }
  }
  return "";
}
//LL分析过程
void analyzeLL(){
  cout << "\nLL分析过程\n";
  cout << setw(20) << "stack" << setw(10) << "input" << setw(20) << "expression";
  cout << endl;
  analyzeStack.push('#');
  //#入栈
  analyzeStack.push(S);
  //开始符入栈
  displayLL();
  char X = analyzeStack.top();
  while (X != '#'){
    char a = strInput[index];
    if (X == a){
      action = "";
      analyzeStack.pop();
      index++;
    }
    else if (VT.count(X))
      return;//找到终结符,出栈
    else if (find(X, a) == "")
      return;
    else if (find(X, a) == "e"){
      analyzeStack.pop();
      action = "";
      action += X;
      action += "->e";
    }//空字,出栈
    else{//其余情况,需要按分析表对栈顶元素进行推导
      string str = find(X, a);
      if (str != ""){
        action = "";
        action += X;
        action += "->";
        action += str;
        analyzeStack.pop();
        int len = str.length();
        for (int i = len - 1; i >= 0; i--)
          analyzeStack.push(str[i]);//栈顶元素出栈,按分析表和下一字符将分析表中元素入栈
      }
      else{
        cout << "\nERROR!\n";//出错,直接返回
        return;
      }
    }
    X = analyzeStack.top();
    displayLL();
  }
}
int main(){
  //从文件读取文法
  read();
  //识别非终结符与终结符
  identifyVnVt();
  //消除左递归
  leftRecursion();
  //消除回溯
  leftTraceback();
  //增广
  deleteor();
  cout << "\n再次识别终结符与非终结符\n";
  //再次识别非终结符与终结符
  identifyVnVt2();
  //求first与follow,初始化
  init();
  //建立分析表
  createTable();
  cout << "\n请输入待分析的语句\n";
  cin >> strInput;
  strInput += "#";
  cout << strInput << endl;
  analyzeLL();
  return 0;
}

输入文件(test.txt)

E->E+T|T
T->T*F|F
F->(E)|i


目录
相关文章
|
2月前
|
网络安全
编译原理复习二:Top-Down分析LL(1)文法的判断与LL(1)分析表的构造(附题目与答案 超详细)
编译原理复习二:Top-Down分析LL(1)文法的判断与LL(1)分析表的构造(附题目与答案 超详细)
330 1
|
2月前
编译原理复习三:Bottom-Up LR(0)自动机构造 SLR(1)分析表与分析器的构造(附题目与答案 超详细)
编译原理复习三:Bottom-Up LR(0)自动机构造 SLR(1)分析表与分析器的构造(附题目与答案 超详细)
76 0
|
2月前
R语言表与因子(详细知识点,深入知识点后续会补充!)
R语言表与因子(详细知识点,深入知识点后续会补充!)
22 2
|
2月前
|
存储 编译器 测试技术
【编译原理】LL(1)分析法:C/C++实现
【编译原理】LL(1)分析法:C/C++实现
367 0
|
存储 算法
编译原理 实验三 LL(1)分析法(LL1分析表的自动生成)
编译原理 实验三 LL(1)分析法(LL1分析表的自动生成)
688 0
编译原理 实验三 LL(1)分析法(LL1分析表的自动生成)
|
存储 算法
编译原理 实验四 LR(0)分析法(LR0分析表的自动生成)
编译原理 实验四 LR(0)分析法(LR0分析表的自动生成)
1298 0
编译原理 实验四 LR(0)分析法(LR0分析表的自动生成)
|
存储 Go C语言
编译原理,C语言实现LR(0)分析(扩展文法的生成、项目集规范簇的生成、ACTION GOTO表的生成、句子的分析)
注:代码生成的项目集规范簇、ACTION GOTO表的顺序可能和课本、教材、参考答案的顺序不同,但这并不影响分析过程的正确性,毕竟机器是按规律办事的😄
439 0
编译原理,C语言实现LR(0)分析(扩展文法的生成、项目集规范簇的生成、ACTION GOTO表的生成、句子的分析)
编译原理 实验四 LR(0)分析法(LR0分析表的自动生成) 完整代码
编译原理 实验四 LR(0)分析法(LR0分析表的自动生成) 完整代码
273 0
|
存储 自然语言处理 算法
语法设计——基于LL(1)文法的预测分析表法
语法设计——基于LL(1)文法的预测分析表法
240 0
语法设计——基于LL(1)文法的预测分析表法
