文件系统里面没有 /dev/input/mice 文件的解决办法

简介: 文件系统里面没有 /dev/input/mice 文件的解决办法

问题

前阵子使用一块新板子的开发嵌入式系统,在做界面的过程中,发现移植的根文件系统里面没有/dev/input/mice文件,虽然接了鼠标时候会生成一个event0,但mice文件的数据和event0的数据是不一样的,所以想看看能不能让系统里有支持/dev/input/mice文件。



解决过程

1、在网上搜索系统里为什么没有/dev/input/mice?,没有找到想要的答案!!!

看了一些文章后,发现大部分文章都是直接就可以使用/dev/input/mice文件,产生一个想法:会不会是编译内核时,缺少了哪些配置导致的,然后执行make menuconfig重新配置内核,按斜杠键/搜索mice,没有任何相关信息。


2、接着又在内核源码的根目录使用grep "/dev/input/mice" -rnw ./搜索到很多txt文件,从中找到一个./Documentation/input/input.txt的文件可能会有帮助。

从这个txt文件摘抄下面这段话,意思是要先加载模块,再创建设备节点,最后指定GPM 使用节点。按照命令操作,没有 gpm 命令。

2. Simple Usage
~~~~~~~~~~~~~~~
  For the most usual configuration, with one USB mouse and one USB keyboard,
you'll have to load the following modules (or have them built in to the
kernel):
  input
  mousedev
  keybdev
  usbcore
  uhci_hcd or ohci_hcd or ehci_hcd
  usbhid
  After this, the USB keyboard will work straight away, and the USB mouse
will be available as a character device on major 13, minor 63:
  crw-r--r--   1 root     root      13,  63 Mar 28 22:45 mice
  This device has to be created.
  The commands to create it by hand are:
  cd /dev
  mkdir input
  mknod input/mice c 13 63
  After that you have to point GPM (the textmode mouse cut&paste tool) and
XFree to this device to use it - GPM should be called like:
  gpm -t ps2 -m /dev/input/mice
  And in X:
  Section "Pointer"
      Protocol    "ImPS/2"
      Device      "/dev/input/mice"
      ZAxisMapping 4 5
  EndSection
  When you do all of the above, you can use your USB mouse and keyboard.

3、最后尝试在内核配置中搜到mousedev,找到了有点相关的选项,发现都被关闭了。


3、最后尝试在内核配置中搜到mousedev,找到了有点相关的选项,发现都被关闭了。

Device Drivers  --->
    Input device support  --->
        <*>   Mouse interface


重新编译成功后,烧到板子了,可以找到/dev/input/mice文件了


总结

系统里没有/dev/input/mice的原因,可能是编译内核时,没有配置加载mousedev模块,需要重新配置内核,配置路径如下:

Device Drivers  --->
    Input device support  --->
        <*>   Mouse interface
