简介: Spring5参考指南:IOC容器

文章目录



最近在翻译Spring Framework Documentation 5.1.8.RELEASE. 觉得还是可以系统的将Spring5的知识点系统的再整理一下,于是有了这个Spring5参考指南系列,教程会一直更新,翻译也会同步进行,敬请期待。


为什么使用Spring5


Spring经过这么多年的发展,已经成为既定的企业级J2EE标准,其最大的优点即是轻量级和其最核心的IOC容器。 Spring最新的版本已经到了5.1.8,Spring5提供了很多新的特性,个人认为最主要的有3点:


  • 使用JDK8的新特性
    最引人注意的是Spring5使用了JDK8中的lambda表达式,让代码变得更加简洁。


  • 响应式编程支持
    响应式编程是Spring5中最主要的特性之一,响应式编程提供了另一种编程风格,专注于构建对事件做出响应的应用程序。 Spring5 包含响应流和 Reactor。


  • 响应式web框架
    Spring5提供了一个最新的响应式Web框架,Spring WebFlux,在编程理念和使用习惯方面和之前的传统Web框架都有了很大的区别。


当然,我们要拥抱新技术新变化,那么快来学习Spring5吧。


什么是IOC容器


IOC也称为依赖注入(DI)。它是指对象仅通过构造函数参数、工厂方法的参数或从工厂方法构造或返回对象实例后,通过在其上设置的属性来定义其依赖项(即与之一起工作的其他对象)的过程。


简单点说就是通过配置的参数来构造对象,然后通过配置的属性来实例化其依赖对象。一切都是通过配置来完成的,而不是使用通常的Java new方法来创建对象,也不需要手动去查找或者实例化其依赖对象,一切的一切都是通过Spring IOC容器来实现的。


IOC容器的两个主要包是:org.spring framework.beans和org.springframework.context包。


如果想使用IOC容器,下面两个依赖是必须的:


<dependency>
      <groupId>org.springframework</groupId>
      <artifactId>spring-core</artifactId>
      <version>5.1.8.RELEASE</version>
    </dependency>
    <dependency>
      <groupId>org.springframework</groupId>
      <artifactId>spring-context</artifactId>
      <version>5.1.8.RELEASE</version>
    </dependency>


IOC容器中有两个非常重要的类:BeanFactory和ApplicationContext。


ApplicationContext是BeanFactory的子类,BeanFactory提供了对Bean的操作接口,ApplicationContext则是表示容器本身,提供了bean操作之外的如AOP接入,事件处理,消息资源接入和应用程序上下文等非常有用的特性。


org.springframework.context.ApplicationContext接口代表着SpringIOC容器,它负责实例化、配置和组装bean。容器通过读取配置元数据获取关于要实例化、配置和组装的对象的指令。配置元数据以XML、Java注释或Java代码来表示。它定义了组成应用程序的对象以及这些对象之间的丰富依赖关系。


如果你是创建一个单体应用,那么Spring提供了两个非常有用的ApplicationContext实现,ClassPathXMLApplicationContext或FileSystemXMLApplicationContext。


ClassPathXMLApplicationContext是从类路径去加载要装载的配置,

FileSystemXMLApplicationContext是从文件路径去装载。


你只需要在配置中,定义你需要使用的业务对象(POJO),在创建和初始化

ApplicationContext之后,您就拥有了一个完全配置且可执行的系统或应用程序.




配置元数据


配置配置,Spring的本质就是通过配置来展示和构建业务对象,通常来说,我们可以使用XML文件来配置,当然现在我们也可以使用Java注解和Java代码来实现。


Spring配置由容器必须管理的至少一个或多个bean定义组成。基于XML的配置元数据通常使用来表示。Java配置通常在@Configuration中使用@bean注解的方法。


下面是一个基本的基于XML的定义 daos.xml:


<?xml version="1.0" encoding="UTF-8"?>
<beans xmlns="http://www.springframework.org/schema/beans"
       xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
       xsi:schemaLocation="http://www.springframework.org/schema/beans
        https://www.springframework.org/schema/beans/spring-beans.xsd">
    <bean id="accountDao"
          class="com.flydean.daos.JpaAccountDao">
        <!-- additional collaborators and configuration for this bean go here -->
    </bean>
    <bean id="itemDao" class="com.flydean.daos.JpaItemDao">
        <!-- additional collaborators and configuration for this bean go here -->
    </bean>
    <!-- more bean definitions for data access objects go here -->
</beans>


其中id是bean的唯一标记,class是bean的类路径。


实例化容器


Spring容器有很多种实例化方法,比如上面讲的单体应用的两个类:


ApplicationContext context = new ClassPathXmlApplicationContext("services.xml", "daos.xml");


上面已经列出了daos.xml , 这里我们再列出services.xml :


<?xml version="1.0" encoding="UTF-8"?>
<beans xmlns="http://www.springframework.org/schema/beans"
    xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
    xsi:schemaLocation="http://www.springframework.org/schema/beans
        https://www.springframework.org/schema/beans/spring-beans.xsd">
    <!-- services -->
    <bean id="petStore" class="com.flydean.services.PetStoreService">
        <property name="accountDao" ref="accountDao"/>
        <property name="itemDao" ref="itemDao"/>
        <!-- additional collaborators and configuration for this bean go here -->
        <constructor-arg ref="accountDao"/>
    </bean>
    <!-- more bean definitions for services go here -->
</beans>


service.xml 里面主要定义了对在定义在daos.xml中的bean的引用。这里的引用方式是通过ref. ref引用了daos.xml里面bean的id。


XML嵌套


除了上面例子中在创建ApplicationContext的时候,加载多个xml文件,其实我们也可以在xml中通过import来引入其他的xml文件。


<import resource="daos.xml"/>


resource配置的是要引入的xml的路径,可以使用相对路径和绝对路径。不建议使用相对路径“…”来引用父目录中的文件。这样做会创建对当前应用程序外部文件的依赖关系。直接使用绝对路径又会影响不同部署环境下文件路径的位置。所以比较好的方法是在运行时根据JVM系统属性解析的“$…”占位符。


groovy bean定义DSL


除了xml定义,Spring也可以使用groovy bean来配置。


下面是daos.groovy的定义:


import com.flydean.daos.JpaAccountDao;
import com.flydean.daos.JpaItemDao;
beans{
    accountDao(JpaAccountDao){
    }
    itemDao(JpaItemDao){
    }
}


很简单,就是定义了2个bean。


下面是services.groovy的定义:


import com.flydean.services.PetStoreService
beans {
    petStore(PetStoreService, accountDao){
        accountDao=accountDao
        itemDao=itemDao
    }
}


使用容器


ApplicationContext是高级工厂的接口,它能够维护不同bean的注册及其依赖。通过使用方法T getBean(String name, Class requiredType),获取到bean的实例。


ApplicationContext允许您读取bean定义并访问它们,如下例所示:


// create and configure beans
        ApplicationContext context = new ClassPathXmlApplicationContext("services.xml", "daos.xml");
        // retrieve configured instance
        PetStoreService service = context.getBean("petStore", PetStoreService.class);
        // use configured instance
        List<String> userList = service.getUsernameList();


上面讲到了groovy bean配置, 下面是怎么使用groovy bean:


// create and configure beans with groovy
        //daos.groovy 必须写在services.groovy前面,否则会报bean找不到的错误
        ApplicationContext context = new GenericGroovyApplicationContext("daos.groovy","services.groovy");
        // retrieve configured instance
        PetStoreService service = context.getBean("petStore", PetStoreService.class);
        // use configured instance
        List<String> userList = service.getUsernameList();


使用groovy的时候请注意, daos.groovy 必须写在services.groovy前面,否则会报bean找不到的错误。


还可以使用XmlBeanDefinitionReader和GenericApplicationContext结合的方式:


GenericApplicationContext context = new GenericApplicationContext();
        //reader with xml
        new XmlBeanDefinitionReader(context).loadBeanDefinitions("services.xml", "daos.xml");


你也可以使用GroovyBeanDefinitionReader来加载Groovy文件,如下所示:


GenericApplicationContext context = new GenericApplicationContext();
new GroovyBeanDefinitionReader(context).loadBeanDefinitions("services.groovy", "daos.groovy");


本教程的源代码可以参照:spring5-core-workshop 中的container模块。
